描述

IS200JPDCG1ABA 用RS-232C通過骨干連接器在DSPX與工具和鍵盤端口之間進行通信

勵磁機ISBus板，如IS200JPDCG1ABA，是一種專用的通信接口板，IS200JPDCG1ABA主要應用于勵磁機的控制系統。它主要用于在勵磁機的M1、M2和C控制器之間傳輸數據。

這種板卡是一種3U高的模塊，通常位于DSPX下方的控制機架中。它通過前面板上的光纖連接器接收來自發電機磁場（必要時還包括勵磁機）的電流和電壓信號，并將這些信號接收和傳輸?shù)浇拥貦z測模塊。此外，它還通過控制背板接收光纖反饋信號，并將其傳輸?shù)紻SPX控制器。同時，它還使用RS-232C通過骨干連接器在DSPX與工具和鍵盤端口之間進行通信。此外，它還包括用于冗余激勵器的ISBus接口電子設備。

勵磁機ISBus板（如IS200EISBH1A）在勵磁機的控制系統中具有多種主要功能。以下是其主要功能：

數據傳輸：它是用于M1、M2和C控制器之間的獨特通信板，負責在這些控制器之間傳輸數據。

信號接收與傳輸：通過前面板上的光纖連接器，接收來自發電機磁場（必要時還包括勵磁機）的電流和電壓信號，并將這些信號傳輸?shù)浇拥貦z測模塊。

光纖反饋信號接收：通過控制背板接收光纖反饋信號，并將其傳輸?shù)紻SPX控制器。

RS-232C通信：使用RS-232C協議，通過骨干連接器在DSPX與工具和鍵盤端口之間進行通信。

冗余激勵器接口：還包括用于冗余激勵器的ISBus接口電子設備，這意味著在勵磁機系統中，如果有一個激勵器出現故障，另一個冗余的激勵器可以接管，保證系統的持續運行。

總的來說，勵磁機ISBus板IS200JPDCG1ABA 是勵磁機控制系統中非常關鍵的組件，它確保了數據的有效傳輸、信號的接收與傳輸，以及與其他設備和模塊的通信，從而保證勵磁機的穩定運行和安全性。

IS200JPDCG1ABA 用RS-232C通過骨干連接器在DSPX與工具和鍵盤端口之間進行通信

Exciter ISBus board, such as IS200JPDCG1ABA, is a special communication interface board, IS200JPDCG1ABA is mainly used in the control system of exciter. It is mainly used to transfer data between the M1, M2 and C controllers of the exciter.

The board is a 3U high module, usually located in the control rack under the DSPX. It receives current and voltage signals from the generator’s magnetic field (and exciter if necessary) through fiber optic connectors on the front panel, and receives and transmits these signals to the ground detection module. In addition, it receives fiber feedback signals through the control backplane and transmits them to the DSPX controller. At the same time, it also uses the RS-232C to communicate between the DSPX and the tools and keyboard ports via a backbone connector. In addition, it includes ISBus interface electronics for redundant exciters.

Exciter ISBus board (such as IS200EISBH1A) has several main functions in the exciter control system. Here are its main functions:

Data transfer: It is a unique communication board for the M1, M2, and C controllers and is responsible for transferring data between these controllers.

Signal reception and transmission: Current and voltage signals from the generator’s magnetic field (including the exciter if necessary) are received through optical fiber connectors on the front panel, and these signals are transmitted to the ground detection module.

Fiber feedback reception: The fiber feedback signal is received through the control backplane and transmitted to the DSPX controller.

RS-232C communication: Use RS-232C protocol to communicate between DSPX and tools and keyboard ports via backbone connectors.

Redundant exciter interface: Also includes ISBus interface electronics for redundant exciter, which means that in the exciter system, if one exciter fails, another redundant exciter can take over, ensuring continuous operation of the system.

In general, the exciter ISBus board IS200JPDCG1ABA is a very critical component in the exciter control system, which ensures the effective transmission of data, the reception and transmission of signals, and the communication with other equipment and modules, so as to ensure the stable operation and safety of the exciter.
