描述

IS200TBCIH2C? ? 接觸輸入組隔離終端板

IS200TBCIH2C是由GE制造的板組件。這是一塊小型電路板,設計用作Mark VI系統的端子板。Mark VI是GE發布的燃?xì)庹羝啓C(jī)管理系統，作為
“Speedtronic”系列的一部分，始于20世紀60年代的MKI,延續到20世紀90年代的MKVI和MKVle。

IS200TBCIH2C是一種接觸輸入 組隔離(TBCI)端子板。該板由兩個端子板和三個電纜連接器組成。每個端子板(TB1/TB2)都有24個螺紋接頭，即12
個觸點。這些觸點的接線使用多達#12 AWG電線。這些板是屏障型端子板，可以從板上拔下進行維護。電纜連接器是帶鎖扣件的DC-37(母)連接
器。這些被標記為JT1/JS1/JR1。 該板有兩個電源輸入插頭。這些標記為JE1/JE2。 電路板被一個金屬框架包圍， 該框架包括-個屏蔽端子條/棒。

IS200TBCIH2C具有濾波器，可降低高頻噪聲并抑制各輸入端的浪涌。每路輸入使用一對端點，一個螺釘提供正直流源，第二個端點提供電路板回
路。前21路輸入的電流負載為每點2.5 mA。最后三個具有10 mA負載。該板沒有硬件設置或跳線?？梢允褂猛ㄓ秒姎夤境霭嫖颎EH-6421找到診
斷信息。

IS200TBCIH2C? ? 接觸輸入組隔離終端板

The IS200TBCIH2C is a board assembly manufactured by GE. This is a small circuit board designed to be used as a terminal board for Mark VI systems. Mark VI is a gas steam turbine management system released by GE as
Part of the “Speedtronic” series, which began with the MKI in the 1960s and continued with the MKVI and MKVle in the 1990s.

The IS200TBCIH2C is a contact Input Group isolation (TBCI) terminal board. The board consists of two terminal boards and three cable connectors. Each terminal board (TB1/TB2) has 24 threaded connectors, i.e. 12
A contact. These contacts are wired using up to #12 AWG wires. These boards are barrier terminal boards that can be unplugged for maintenance. The cable connector is a DC-37(female) connection with a locking fasteners
A surname These are labeled JT1/JS1/JR1. The board has two power input plugs. These are labeled JE1/JE2. The board is surrounded by a metal frame that includes a shielded terminal strip/bar.

The IS200TBCIH2C features a filter to reduce high-frequency noise and suppress surges at each input. Each input uses a pair of endpoints, with one screw providing a straight stream source and the second endpoint providing a circuit board back
Road. The current load of the first 21 inputs is 2.5 mA per point. The last three have a 10 mA load. The board has no hardware Settings or jumpers. Medical consultations can be found using the General Electric Company publication GEH-6421
Break the message.
