描述

IS2020RKPSG3A VME機架電源

產品描述
IS2020RKPSG3A在Mark VI系統中用作VME機架電源。Mark VI是通用電氣創建和發布的最后一批Speedtronic蒸汽或燃?xì)廨啓C(jī)管理系統之一。這條線的渦輪機管理運行從1960年代末，當他們發布了馬克1系統通過90年代與釋放最后兩個系統，馬克6和馬克VIe。馬克六，它可以建立在單一或TMR(三模冗余)形式，是圍繞一個中央控制模塊。這連接到接收從連接到系統的其他板輸入的終端板。控制模塊還連接到操作員界面，或HMI，允許通過Windows平臺訪問系統數據。

IS2020RKPSG3A是VME機架電源的七個(主要)版本之一。這些版本中的每一個都有不同的輸入和輸出要求。IS2020RKPSG3A的額定輸出功率為400W。其額定輸入電壓為125 Vdc。該模塊有一個Status ID輸出，一個遠程+28V PSA輸出，以及額外的五個+28V PSA輸出。該模塊被設計安裝在VME控制和接口機架的右側。

IS2020RKPSG3A模塊有一個帶有撥動開關的前面板，該開關是模塊上唯一的用戶控制。模塊故障可通過此撥動開關復位。面板也有三個LED指示燈，包括綠色，紅色和黃色LED。上一段提到的連接(PSA輸出)位于設備的頂部和底部。機組的側面設計了許多金屬翅片，作為散熱組件。

IS2020RKPSG3A VME機架電源

Product Description
The IS2020RKPSG3A functions as a VME Rack Power supply within the Mark VI system. ?The Mark VI is one of the last Speedtronic steam or gas turbine management systems created and released by GE. ?This line of turbine management ran from the late 1960s when they released the Mark I system through the 1990s with the release of the final two systems, the Mark VI and the Mark VIe. The Mark VI, which can be built in either Simplex or TMR (triple modular redundant) form, is built around a central Control Module. This connects to termination boards that receive inputs from other boards connected to the system. ?The Control Module is also connected to an Operator Interface, or HMI, that allows access via a Windows platform to system data.

The IS2020RKPSG3A is one of seven (major) versions of the VME Rack Power Supply. ?Each of these versions has different input and output requirements. The IS2020RKPSG3A has an output rating of 400W. Its input voltage rating is 125 Vdc.? The module has a Status ID output, a remote +28V PSA output, and an additional five +28V PSA outputs. The module is designed to mount to the right side of the VME control and interface racks.

The IS2020RKPSG3A module has a front faceplate with a toggle switch that is the only user control on the module. ??Module faults can be reset using this toggle switch. The faceplate also has three LED indicators, including a green, a red, and a yellow LED. ?Connections mentioned in the previous paragraph (PSA outputs) are located on the top and bottom of the unit. The side of the unit is designed with a number of metal fins that function as a heat sink component.
