IS210AEDBH4AGD Mark VI 印刷電路板

產品描述
IS210AEDBH4AGD是由GE制造的Mark VI系統的板組件。Mark VI系統用于管理燃氣輪機和蒸汽輪機，并具有集成的HMI/操作員界面，允許用戶使用特殊設計的軟件(如GE的simplicity圖形平臺)訪問系統數據。

IS210AEDBH4AGD為橋接接口卡。該組件的前表面有許多連接器，包括標有574 9771-1 1301的直角電纜連接器。有兩個頭連接器，有六個或四個位置，但每個有兩個垂直引腳。該板有9個雄性垂直引腳連接器，范圍從6引腳到10引腳。電路板也有四個插頭，每個插頭有三個位置。

IS210AEDBH4AGD在前表面和后表面都有組件。背面主要是電容器和電阻器，但也有二極管和晶體管。前表面還有電容器和電阻器，包括20個金屬薄膜電阻器。它也有二極管和晶體管。前表面有四個來自Bicron的變壓器。這些標記為B9178，是封裝的開關模式/脈沖變壓器，旨在滿足BIL額定值的高可靠性要求。變壓器的Hipot電平為5 KVAC，開關頻率為10KHz至500khz。集成電路有超過175種，包括只讀芯片、振蕩芯片等。

IS210AEDBH4AGD在9個地點進行鉆井。這塊木板的表面有許多槽。這些槽在其長度上由集成電路或變壓器填充。這塊板上標有幾個代碼。有關該板及其組件的更多信息可通過制造商出版物找到。

IS210AEDBH4AGD Mark VI 印刷電路板

Product Description
The IS210AEDBH4AGD is a component manufactured by GE as a board component for the Mark VI system. ?The Mark VI system was created to manage gas and steam turbines and features an integrated HMI/Operator interface that allows users access to system data using specially designed software like GE’s CIMPLICITY graphics platform.

The IS210AEDBH4AGD is a Bridge Interface Card. ?This component has many connectors on its front surface, including a right-angled cable connector marked 574 9771-1 1301. ?There are two header connectors with six or four positions but two vertical pins each. The board has nine male vertical pins connectors ranging from six pins to ten pins. ?The board also has four plugs with three positions each.

The IS210AEDBH4AGD has components on the front surface and on the back surface. ?The back surface is primarily capacitors and resistors, but also has diodes and transistors. ?The front surface also has capacitors and resistors, including twenty metal film resistors. It also has diodes and transistors. ?The front surface has four transformers from Bicron. These are marked B9178 and are encapsulated switch mode/pulse transformers designed to meet the high-reliability demands for BIL ratings. ?The transformers have a Hipot level of 5 KVAC with a switching frequency of 10KHz to 500 KHz. Integrated circuits, of which there are over 175, include read-only chips, oscillating chips, and others.

The IS210AEDBH4AGD is drilled in nine locations. ?The board has many slots cut into its surface. These slots are populated over their length by integrated circuits or transformers. ?The board is marked with several codes. More information about this board and its components may be found through manufacturer publications.
