  1. 型號：IS220PDOAH1A
  2. 品牌：GE（通用電氣）
  3. 系統：Speedtronic Mark VIe燃?xì)廨啓C(jī)控制系統
  4. 類型：離散輸出組件

描述

產品細節說明：IS220PDOAH1A GE 離散輸出組件

  • 作用：IS220PDOAH1A通過電氣接口將一個或兩個I/O以太網網絡連接到離散輸出端子板，實現離散量信號的輸出控制。
  • 處理器板：該套件包括一塊由所有Mark VIe分布式I/O套件共享的處理器板，以及一塊專用于離散輸出功能的采集板。
  • 繼電器控制：該電池組最多可控制12個繼電器，并接受來自接線板的反饋。有磁繼電器（如TRLYH1B、C、D和F端子板）和固態繼電器（如TRLYH1E板）可供選擇。
  • 電源與連接：該電池組由三針電源輸入和兩個RJ45以太網連接器供電。輸出通過直接連接到相關端子板連接器的DC-37針連接器進行。
  • 診斷功能：LED指示燈提供視覺診斷，紅外端口允許本地診斷串行通信。

IS220PDOAH1A

產品詳情參數 ：IS220PDOAH1A GE 離散輸出組件

  • 端子板類型：適用于六種不同類型的離散（繼電器）輸出端子板，包括TRLY和SRLY板，但不包括DIN導軌安裝的DRLY板。
  • 系統配置：根據系統需求，可以有不同的配置方式，如Simplex（使用單個I/O包和一個或兩個網絡連接）、Dual（使用兩個I/O包和一個或兩個網絡接口）和TMR（使用三個I/O包，每個包有一個網絡連接）。
  • 環境適應性：該組件可在0至65攝氏度的溫度范圍內使用，即使在高額定溫度下，也不需要風扇進行冷卻。

IS220PDOAH1A GE? 應用領域：

IS220PDOAH1A作為GE Speedtronic Mark VIe燃?xì)廨啓C(jī)控制系統中的一個關鍵組件，在離散量信號的輸出控制方面發揮著重要作用。其高可靠性、兼容性和靈活性使其成為燃?xì)廨啓C(jī)控制系統中的優選產品。

Product details: IS220PDOAH1A GE discrete output component
Function: IS220PDOAH1A connects one or two I/O Ethernet networks to the discrete output terminal board through electrical interfaces, achieving output control of discrete signals.
Processor Board: This kit includes a processor board shared by all Mark VIe distributed I/O kits, as well as an acquisition board dedicated to discrete output functionality.
Relay control: This battery pack can control up to 12 relays and receive feedback from the terminal block. There are magnetic relays (such as TRLYH1B, C, D, and F terminal boards) and solid-state relays (such as TRLYH1E boards) available for selection.
Power and Connection: The battery pack is powered by a three pin power input and two RJ45 Ethernet connectors. The output is carried out through a DC-37-pin connector directly connected to the relevant terminal board connector.
Diagnostic function: LED indicator lights provide visual diagnosis, and the infrared port allows local diagnostic serial communication.
Product details parameters: IS220PDOAH1A GE discrete output component
Terminal board type: Suitable for six different types of discrete (relay) output terminal boards, including TRLY and SRLY boards, but not including DRLY boards installed on DIN rails.
System configuration: According to system requirements, there can be different configuration methods, such as Simplex (using a single I/O package and one or two network connections), Dual (using two I/O packages and one or two network interfaces), and TMR (using three I/O packages, each with one network connection).
Environmental adaptability: This component can be used within a temperature range of 0 to 65 degrees Celsius, and does not require a fan for cooling even at high rated temperatures.
IS220PDOAH1A GE application areas:

IS220PDOAH1A, as a key component of the GE Speedtronic Mark VIe gas turbine control system, plays an important role in the output control of discrete signals. Its high reliability, compatibility, and flexibility make it the preferred product in gas turbine control systems.
