描述

MS20-1600SAAEHC 通信系統中完成信息交換功能的設備

赫斯曼交換機MS20-1600SAAEHC是一款在通信系統中完成信息交換功能的設備，屬于化工業級骨干網三層交換機，并具有專業版軟件。它支持多達48個千兆端口，其中8個為千兆電口，8個為千兆Combo口，其余32個千兆端口由介質模塊拓展。

在軟件功能方面，MS20-1600SAAEHC支持遠程訪問、診斷、過濾和冗余等增強版功能，同時還包括增強的安全、擴展的診斷和冗余功能。此外，它還支持帶能量緩沖的實時時鐘、組播GMRP、IEEE 802.1D SNMP V3、SSH、IEEE802.1X認證、MAC/IP優先級、TOS-Prio-Mapping、流量整形（單播、組播、廣播）、ingress/egress等功能。

在硬件性能方面，MS20-1600SAAEHC具有環網典型自愈時間小于50ms的冗余性能，支持HIPER-Ring、快速生成樹RSTP、環間耦合（主/從）、冗余供電、冗余信號觸點、動態和靜態鏈路聚合（最多7個trunk，每個trunk最多8個端口，支持LACP）等功能。

此外，MS20-1600SAAEHC還具有其他特性，如相對濕度（無凝結）范圍為10% ~ 95%，工作溫度為0°C ~ 60°C，存儲溫度為-40°C ~ 70°C，電壓為24V DC，尺寸為202133100mm，重量為880g等。

MS20-1600SAAEHC 通信系統中完成信息交換功能的設備

Hersman switch MS20-1600SAAEHC is a device to complete the information exchange function in the communication system, belongs to the chemical industry backbone network layer 3 switch, and has a professional version of the software. It supports up to 48 gigabit ports, of which 8 are Gigabit electrical ports, 8 are Gigabit Combo ports, and the remaining 32 gigabit ports are expanded by the media module.

In terms of software features, the MS20-1600SAAEHC supports enhanced features such as remote access, diagnostics, filtering and redundancy, as well as enhanced security and extended diagnostics and redundancy. In addition, It also supports real-time clock with energy buffering, multicast GMRP, IEEE 802.1D SNMP V3, SSH, IEEE802.1X authentication, MAC/IP priority, TOS-Prio-Mapping, traffic shaping (unicast, multicast, broadcast), ingress/egress, and more.

In terms of hardware performance, the MS20-1600SAAEHC has the redundancy performance of the typical self-healing time of the ring network less than 50ms, and supports HIPER-Ring, fast spanning tree RSTP, inter-ring coupling (master/slave), redundant power supply, redundant signal contacts, dynamic and static link aggregation (up to 7 trunk, up to 7 trunk, up to 7 trunk, up to 7 trunk, up to 7 trunk, up to 7 trunk, up to 7 trunk. Each trunk has a maximum of eight ports and supports LACP functions.

In addition, the MS20-1600SAAEHC also has other characteristics, such as relative humidity (no condensation) range of 10% to 95%, operating temperature of 0°C to 60°C, storage temperature of -40°C to 70°C, voltage of 24V DC, size of 202133100mm, weight of 880g and so on.
