MVME320B VMEbus智能溫徹斯特/軟盤控制器模塊
部件編號:01-W3483B, 01-W3484B 02D, 01-W3484B 02C, 01-W3483B 02B
MVME320B VMEbus智能溫徹斯特/軟盤控制器模塊摩托羅拉
制造商:摩托羅拉
模型: MVME320B
附加信息:VMEbus智能溫徹斯特/軟盤控制器模塊
預計運輸規模
外形尺寸:263 × 58 × 28mm
重量:.4.3公斤
原產國:美國
產品描述
摩托羅拉68K CISC CPU的調試包用戶手冊提供了所有摩托羅拉68000 CISC CPU和MPU VMEmodule板的板載固件包的一般信息。本文檔分為兩部分。第1部分(68KBUG1/D3)包含目錄和第1章到第3章。第2部分(68KBUG2/D3，本卷)包含第4章和第5章，附錄A到I，和索引。本手冊適用于任何想要設計OEM系統，為現有兼容系統提供額外功能或在實驗室環境中進行實驗的人。
本手冊涉及以下固件包和板:本手冊中固件包稱為16XBug。這些板被稱為MVME16X。
本手冊描述了調試器、調試器命令集、單行匯編/反匯編器和系統調用。這些功能元素對于所有固件包都是通用的。每個固件包的診斷手冊中都有安裝、啟動、診斷測試和環境參數的說明。
假定具有計算機和數字邏輯的基本知識。摩托羅拉和摩托羅拉標志是摩托羅拉公司的注冊商標。SYSTEM V/68是摩托羅拉公司的商標。Timekeeper和Zeropower是SGS-THOMSON Microelectronics的商標。
特點:
高性能數據通道
前面板狀態指示燈
三個前面板接口連接
單槽位VME模塊
艾默生/摩托羅拉MVME320A VMEbus智能溫徹斯特/軟盤控制器模塊符合單槽VMEbus形式因素。它提供了系統內存和ST506溫徹斯特和/或軟盤驅動器之間的高性能數據通道;最多兩個溫徹斯特和兩個或四個軟盤驅動器。該單元具有故障通知LED和前面板上的三個接口連接。
MVME320B VMEbus智能溫徹斯特/軟盤控制器模塊
Part Number: 01-W3483B, 01-W3484B 02D, 01-W3484B 02C, 01-W3483B 02B
MVME320B VMEbus Intelligent Winchester / Floppy Disk Controller Module MOTOROLA
Manufacturers ：MOTOROLA
Model(s)? ：MVME320B
Additional Information ：VMEbus Intelligent Winchester / Floppy Disk Controller Module
Estimated Shipping Size
Dimensions: 263 × 58 × 28mm
Weight:.4.3?kg
Country of Origin: United States of America
Products Description
The Debugging Package for Motorola 68K CISC CPUs User’s Manual provides general information for the onboard firmware package for all Motorola 68000 CISC CPU and MPU VMEmodule boards. This document is bound in two parts. Part 1 (68KBUG1/D3) contains the Table of Contents and Chapters 1 through 3. Part 2 (68KBUG2/D3, this volume) contains Chapters 4 and 5, Appendices A through I, and the Index. This manual is intended for anyone who wants to design OEM systems, supply additional capability to an existing compatible system, or work in a lab environment for experimental purposes.
The following firmware packages and boards are covered in this manual: The firmware packages are referred to as 16XBug in this manual. The boards are referred to as MVME16X.
This manual describes the debugger, the debugger command set, the one-line assembler/disassembler, and system calls. These functional elements are common to all firmware packages. Installation, start-up, diagnostics tests, and environmental parameters are described in the diagnostic manuals for each of the firmware packages.
A basic knowledge of computers and digital logic is assumed. Motorola and the Motorola symbol are registered trademarks of Motorola, Inc. SYSTEM V/68 is a trademark of Motorola, Inc. Timekeeper and Zeropower are trademarks of SGS-THOMSON Microelectronics.
Features:
High Performance Data Channels
Front Panel Status LED
Three Front Panel Interface Connections
Single Slot VME Module
The Emerson / Motorola MVME320A VMEbus Intelligent Winchester/Floppy Disk Controller Module conforms to the single-slot VMEbus form factor. It provides high performance data channels between System memory and ST506 Winchester and/or floppy drives; up to two Winchester and two floppy disk drives or four floppy disk drives. The unit features a fail-inform LED and three interface connections on the front panel.
