MVME3600 帶有 PM604 處理器內存模塊的基本 I/O 模塊
MVME3600-1基本I/O模塊配置:
?VME64
?64位PMC擴展插槽
?2mb的SVGA圖形
?前面板接口:鍵盤，鼠標，軟盤/LED
?64位PCI Mezzanine Connector
?與MVME761過渡模塊兼容
?掃描前面板
部件編號:01-W3170F 01H, 01-W1630B24K
PM604處理器內存模塊配置:
?(2)PowerPC 604處理器:200mhz
?每處理器256 KB緩存
?256mb DRAM
?5mb閃存
?掃描前面板
部件編號:01-W3266F 01H
子卡部件號:01-W3174F 03B
特點:
可定制的平臺
64MB板載ECC dram -高達1GB
可堆疊的基礎I/O，處理器/內存和PMC載波模型
艾默生/摩托羅拉MVME3600和MVME4600是VME處理器模塊，提供了一個優秀的基礎平臺，可以快速，輕松地為各種行業特定應用進行定制。MVME3600和MVME4600 VMEbus板級計算機旨在滿足軍事、航空航天和工業自動化應用的需求，由處理器-存儲器模塊和基本I/O模塊組成，均為6U，組裝成單個雙槽磚。這種模塊化結構允許對處理器模塊進行升級(包括為多處理器實現提供足夠的空間)，并為增加的網絡和大容量存儲擴展接口提供物理空間。DRAM擴展夾層可以將內存升級到最大1GB的ECC DRAM，而無需額外的VME插槽。雙處理器MVME4600的緊密耦合多處理器配置為最苛刻的任務提供了額外的計算能力，包括仿真和數據庫或矩陣操作。
處理器i /O匹配和PCI擴展
MVME3600和MVME4600處理器模塊具有64位PCI連接，允許與基礎I/O模塊配對。連接器和電氣規格的設計細節可從您當?shù)氐哪ν辛_拉代表處獲得。處理器模塊也有一個獨立的PCI連接器來支持PCI擴展載體，如摩托羅拉PMCspan。
內存模塊
MVME3600/4600系列采用模塊化存儲器設計。64MB的DRAM被焊接在處理器內存模塊上。額外的夾層陣列支持從64MB到1GB的附加DRAM。這些RAM201擴展模塊允許現場升級內存容量，并且不需要額外的VME插槽。
MVME3600 帶有 PM604 處理器內存模塊的基本 I/O 模塊
MVME3600-1 Base I/O Module Configuration:
? VME64
? 64 Bit PMC Expansion Slot
? 2 MB SVGA Graphics
? Front Panel Interfaces: Keyboard, Mouse, Floppy/LED
? 64-Bit PCI Mezzanine Connector
? Compatible with MVME761 Transition Module
? Scanbe Front Panel
Part Numbers: 01-W3170F 01H, 01-W1630B24K
PM604 Processor Memory Module Configuration:
? (2) PowerPC 604 Processor: 200 MHz
? 256 KB Cache Per Processor
? 256 MB DRAM
? 5 MB Flash
? Scanbe Front Panel
Part Number: 01-W3266F 01H
Daughter Card Part Number: 01-W3174F 03B
Features:
Customizable Platform
64MB On-Board ECC DRAM—up to 1GB
Stackable Base I/O, Processor/Memory and PMC Carrier Models
The Emerson / Motorola MVME3600 and MVME4600 are VME processor modules that provide an excellent base platform that can be quickly and easily customized for a variety of industry specific applications. Designed to meet the needs of military and aerospace and industrial automation applications, MVME3600 and MVME4600 VMEbus board-level computers consist of a processor-memory module and a base I/O module, both 6U, assembled to form a single two-slot brick. This modular structure allows the processor module to be upgraded (including sufficient space for multiprocessor implementations) and provides the physical space for an increased range of networking and mass storage expansion interfaces. DRAM expansion mezzanines enable memory upgrades to the maximum 1GB of ECC DRAM without requiring additional VME slots.The tightly coupled multiprocessor configuration of the dual processor MVME4600 provides additional computing power for the most demanding tasks, including simulation and database or matrix manipulation.
Processor-I/O Mating and PCI Expansion
MVME3600 and MVME4600 processor modules have a 64-bit PCI connection to allow mating with the base I/O module. Design details for the connector and electrical specifications are available from your local Motorola representative. Processor modules also have a separate PCI connector to support PCI expansion carriers such as Motorola PMCspan.
Memory Modules
The MVME3600/4600 series has a modular memory design. 64MB of DRAM are soldered on board the processor-memory module. Additional mezzanine arrays support from 64MB to 1GB of add-on DRAM. These RAM201 expansion modules allow field upgrades of the memory capacity and do not require additional VME slots.
