PCI-6110 4通道，12位，5 MS/s/ch，同時采樣多功能數據采集
配置:
?PCI卡電壓:僅5v
部件編號:184111D-01, 184111E-01, 184111G-01, 184111K-01
4通道AI(12位，5 MS/s/ch)， 2通道AO, 8通道DIO, PCI多功能I/O設備- PCI?6110是一種同步采樣多功能DAQ設備。它提供模擬I/O、數字I/O、兩個24位計數器和數字觸發器。PCI?6110是各種應用的理想選擇，例如需要同步模擬輸入(AI)、模擬輸出(AO)和數字I/O的激勵/響應應用。它也是42 V汽車應用，雷達，聲納和超聲波的理想選擇。所包含的NI?DAQmx驅動程序和配置實用程序簡化了配置和測量。
根據PCI-6110的尺寸，需要安裝的機箱槽位必須能夠容納PCI模塊的整個長度。
特點:
擴展輸入范圍至±42v
4個同時采樣的模擬輸入，每通道5ms /s
兩個16位模擬輸出，4 MS/s單通道，2.5 MS/s雙通道
8條數字I/O線;兩個24位計數器;模擬和數字觸發
NI PCI-6110 / 6110E具有每個通道專用的模數轉換器(ADC)，可實現最大的設備吞吐量和更高的多通道精度。具有5 MS/s的每通道采樣率，±0.2至±42 V的8個輸入范圍，以及更高的多通道精度。NI PCI-6110具有每通道5 ms /s的采樣率，8個±0.2至±42 V的輸入范圍，2個16位模擬輸出，2個24位計數器/定時器和8條通用數字I/O線，可用于各種應用。一些例子包括:42v汽車應用、瞬態和彈道測量、雷達、聲納、超聲波、高能物理、中頻數字化。
NI-6110和PCI-6110E有區別嗎?
NI響應:NI-6110與PCI-6110E是完全相同的板。該板最初被命名為PCI-6110E，但隨著我們的MIO線的擴展，我們意識到該板不適合e系列組，更適合MIO組。因此，“E”從DAQ板的名稱中刪除。從功能的角度來看，董事會保持不變。
PCI-6110? ? 4通道，12位，5 MS/s/ch，同時采樣多功能數據采集
Configuration:
? PCI Card Voltage: 5 V Only
Part Number: 184111D-01, 184111E-01, 184111G-01, 184111K-01
4-channel AI (12-bit, 5 MS/s/ch), 2-channel AO, 8-channel DIO, PCI Multi-function I/O device – PCI?6110 is a synchronous sampling multi-function DAQ device. It provides analog I/O, digital I/O, two 24-bit counters, and digital triggers. PCI?6110 is ideal for a variety of applications, such as excitation/response applications that require synchronous analog input (AI), analog output (AO), and digital I/O. It is also ideal for 42 V automotive applications, radar, sonar and ultrasound. The included NI?DAQmx driver and configuration utility simplify configuration and measurement.
Based on the dimensions of PCI-6110, the required chassis slot must be able to accommodate the entire length of the PCI module.
Features:
Extended Input Ranges to ±42 V
4 Simultaneously Sampled Analog Inputs, 5 MS/s Per Channel
Two 16-Bit Analog Outputs, 4 MS/s Single Channel, 2.5 MS/s Dual Channel
8 Digital I/O Lines; Two 24-Bit Counters; Analog and Digital Triggering
The NI PCI-6110 / 6110E features a dedicated analog-to-digital converter (ADC) per channel for maximum device throughput and higher multi-channel accuracy. With 5 MS/s per channel sampling rates, eight input ranges from ±0.2 to ±42 V, and higher multi-channel accuracy. With 5 ms /s per channel sampling rates, eight input ranges from ±0.2 to ±42 V, two 16-bit analog outputs, two 24-bit counter/timers and eight general-purpose digital I/O lines, the NI PCI-6110 can be used in a variety of applications. Some examples include: 42 V automotive applications, Transient and ballistics measurements, Radar, sonar, ultrasound, High-energy physics, IF digitization.
Is there a difference between the NI-6110 and the PCI-6110E?
NI Response: The NI-6110 is the exact same board as the PCI-6110E. The board was originally named the PCI-6110E, but as our MIO line expanded, we realized that this board did not fit so well in the E-series group and was better suited for the MIO group. The “E” was therefore dropped from the name of the DAQ board. From a functionality standpoint, the board has remained the same.
