PCI-7334 4 軸 PCI 步進運動控制器
PCI-7334可以控制多達4個軸的步進電機。
部件編號:186307C-03, 186307C-06, 190979C-04, 778417-01
特點:
協調多軸的線性插值
實時系統集成與數據采集或圖像采集板
高性能步進發生器，以確保在高速平滑運動
NI 7330控制器具有先進的運動控制功能，具有易于使用的軟件工具和用于LabVIEW的附加運動VI庫。7330控制器是一款用于PXI和PCI的步進電機控制器。7330為多達四個獨立或協調的運動軸提供完全可編程的運動控制，具有用于限制和家庭開關的專用運動I/O，以及用于通用功能的額外I/O。您可以使用7330運動控制器進行點對點和直線矢量移動，用于步進電機應用。7330控制器增加了使用步進電機執行任意和復雜運動軌跡的能力。步進軸可以開環或閉環方式運行。在閉環模式下，步進軸使用正交編碼器或模擬輸入進行位置和速度反饋(僅限閉環)，并提供步進/方向或順時針(CW) /逆時針(CCW)數字命令輸出。所有步進軸支持全步，半步和微步應用。
7334采用先進的雙處理器架構，使用32位CPU，結合數字信號處理器(DSP)和定制現場可編程門陣列，使控制器成為高性能設備。先進先出(FIFO)總線接口和強大的功能集提供高速通信，同時從主機PC卸載復雜的運動功能，以獲得最佳的命令吞吐量和系統性能。
NI pci – 7334
PCI-7334控制器具有先進的運動控制功能，具有易于使用的軟件工具和用于LabVIEW的附加運動VI庫。7334控制器為多達四個獨立或協調的運動軸提供完全可編程的運動控制，具有用于限制和家庭開關的專用運動I/O以及用于通用功能的額外I/O。您可以使用7334運動控制器進行點對點和直線矢量移動，用于步進電機應用。
4軸步進運動控制器設備-pci?7334專為點對點運動應用而設計。PCI – 7334提供用于協調多個軸運動的線性插值功能,用于與數據采集或圖像采集硬件直接通信的實時系統集成,以及用于確保高速平滑運動的高性能步進生成。
PCI-7334 4 軸 PCI 步進運動控制器
The PCI-7334 can control stepper motors with up to 4 axes.
Part Number :186307C-03, 186307C-06, 190979C-04, 778417-01
Features:
Coordinate linear interpolation for multiple axes
Real-time system integration with data acquisition or image acquisition board
High performance stepper generator to ensure smooth movement at high speed
The NI 7330 controller features advanced motion control features with easy to use software tools and an additional motion VI library for LabVIEW. The 7330 controller is a stepper motor controller for PXI and PCI. The 7330 provides fully programmable motion control for up to four independent or coordinated motion axes, with dedicated motion I/O for limits and home switches, and additional I/O for general-purpose functions. You can use the 7330 motion controller for point-to-point and linear vector movement for stepper motor applications. The 7330 controller adds the ability to perform arbitrary and complex motion trajectories using stepper motors. The stepper shaft can be operated in open or closed loop mode. In closed loop mode, the stepper axis uses an orthogonal encoder or analog input for position and speed feedback (closed loop only) and provides step/direction or clockwise (CW)/counterclockwise (CCW) digital command output. All stepper axes support full step, half step and micro step applications.
The 7334 features an advanced dual-processor architecture that uses a 32-bit CPU, combined with a digital signal processor (DSP) and a custom field programmable gate array (fpga), making the controller a high-performance device. The first in first out (FIFO) bus interface and powerful feature set provide high-speed communication while offloading complex motion functions from the host PC for optimal command throughput and system performance.
NI pci – 7334
The PCI-7334 controller features advanced motion control features with easy-to-use software tools and an additional motion VI library for LabVIEW. The 7334 controller provides fully programmable motion control for up to four independent or coordinated motion axes, with dedicated motion I/O for limits and home switches and additional I/O for general-purpose functions. You can use the 7334 motion controller for point-to-point and straight-line vector movement for stepper motor applications.
4-axis stepper motion Controller device -pci?7334 is designed for point-to-point motion applications. The PCI-7334 provides linear interpolation for coordinating motion across multiple axes, real-time system integration for direct communication with data acquisition or image acquisition hardware, and high-performance step generation for ensuring smooth motion at high speeds.
