PCI-7342 運動控制器設備
2軸步進/伺服運動控制器設備- PCI – 7342適用于簡單和復雜的運動應用。PCI – 7342包括兩個處理器和一個具有多軸插值的實時板載系統。PCI – 7342為嵌入式運動操作或以主機為中心的編程環境提供混合運動軌跡控制和完全協調的圓形、線性、點對點、齒輪和矢量空間控制。
PCI – 7342還為復雜的運動提供輪廓控制。板載CPU采用嵌入式實時操作系統，實現基于事件的多任務控制。通過這種方法，多個運動控制程序和進程可以在控制器上同步運行，獨立于主機PC，并且沒有外部交互，除非主機程序或用戶被配置為主動啟動交互。
具有實時嵌入式操作系統和多軸插補功能，美國國家儀器公司PCI-7342(部件編號:778916-02)是一款用于伺服/步進電機的2軸運動控制器設備。該模型提供了完全協調的齒輪傳動，線性和圓形控制。對于復雜的動作，它還可以提供輪廓能力。集成的CPU使用嵌入式操作系統，具有面向事件的多任務控制。有了這種配置，多個運動控制程序可以由控制器有效地操作，沒有任何滯后和零外部交互，除非由用戶或主機程序啟動。該器件的PID更新速率為62.5至500μs/sample，最大步進頻率為4 MHz。它的編碼器輸入速率為20mhz，功耗為5.7W。
NI PCI-7342具有32個數字I/O通道。這些通用I/O線路中的每一條都可以通過單獨的專用數字I/O連接器(68針)進行訪問。32位數字I/O端口配置為4個8位數字I/O端口。這個運動控制器上的所有數字I/O線都具有可編程的極性和方向。每個輸出電路可以輸出和吸收高達24毫安。該模型通過其數字I/O連接器提供兩個PWM(脈寬調制)輸出。這些PWM輸出用于生成軟件控制器周期波形，每個波形的頻率為32 kHz。
PCI-7342 運動控制器設備
2-axis stepper/servo motion controller device – PCI?7342 is suitable for both simple and complex motion applications. PCI?7342 includes two processors and a real-time onboard system with multi-axis interpolation. PCI?7342 provides hybrid motion trajectory control and fully coordinated circular, linear, point-to-point, gear, and vector space control for embedded motion operations or host-centric programming environments.
PCI?7342 also provides contour control for complex movements. The on-board CPU uses an embedded real-time operating system to implement event-based multi-task control. With this approach, multiple motion control programs and processes can run synchronously on the controller, independent of the host PC, and without external interaction, unless the host program or user is configured to actively initiate the interaction.
Featured with a real-time embedded OS and multiaxis interpolation, the National Instruments PCI-7342 (Part Number: 778916-02) is a 2-axis Motion Controller Device for servo/stepper motors. ?This model offers fully coordinated gearing, linear, and circular control. For complex moves, it can also provide a contouring capability. The integrated CPU uses an embedded operating system with event-oriented multitasking control. With this configuration, multiple motion control programs can be operated by the Controller efficiently without any lags and with zero outside interaction unless initiated by the user or host program. The device has a PID update rate of 62.5 to 500 μs/sample, and a maximum step frequency of 4 MHz. It has an encoder input rate of 20 MHz, and has a power consumption of 5.7W.
The NI PCI-7342 has 32 digital I/O channels. Each of these general purpose I/O lines can be accessed through a separate, dedicated digital I/O connector (68-pin). The 32-bit digital I/O port is configured as four 8-bit digital I/O ports. All digital I/O lines on this Motion Controller have programmable polarity and direction. Each output circuit can source and sink up to 24 mA. This model offers two PWM (pulse width modulation) outputs through its digital I/O connector. These PWM outputs are used to generate software controller periodic waveforms, and have a frequency of 32 kHz each.
