PCI-DAS160216 16 位模擬 I/O 和多功能 PCI 卡
這是一個全尺寸的PCI卡。
配置:
?8差分或16單端輸入通道
?24個數字I/O線
?雙16位模擬輸出
?512采樣FIFO
?6個計數器，24個數字I/O
?軟件兼容CIO-DAS1602/16
特點:
16單端/ 8差分輸入16位模擬輸入
200khz吞吐量
2模擬輸出
(3) 16位Down計數器
數字I/O，計數器/定時器
100針高密度I/O連接器
2個FIFO緩沖16位模擬輸出，更新率高達100khz
PCI- das1602 /16多功能模擬和數字I/O板為PCI總線上的高性能數據采集設定了新的標準。本手冊介紹了PCI-DAS1602/16單板的安裝和使用方法。
PCI- das1602 /16是一款針對PCI總線設計的多功能測控板。該板可用于數據采集、系統定時和工業過程控制等應用。
PCI-DAS1602/16板完全即插即用，沒有開關，跳線或電位器設置。所有的板地址和中斷源都是用軟件設置的。使用可編程板上數字電位器和微調D/A轉換器的軟件校準板。
模擬輸入范圍可通過軟件選擇為雙極或單極。雙極輸入范圍為±10v、±5v、±2.5 V和±1.25 V。單極輸入范圍為0 ~ 10v、0 ~ 5v、0 ~ 2.5 V和0 ~ 1.25 V。PCI- DAS1602/16具有模擬觸發輸入。觸發電平和方向是軟件可配置的。
PCI-DAS1602/16單板包含2個82C54計數器芯片。每個芯片包含三個16位下行計數器，提供時鐘、門和輸出連接。
PCI-DAS160216 16 位模擬 I/O 和多功能 PCI 卡
This unit is a full-sized PCI card.
Configuration:
? Eight differential or 16 single-ended input channels
? 24 digital I/O lines
? Dual 16-bit Analog Outputs
? 512 sample FIFO
? 6 counters, 24 digital I/O
? Software compatible with CIO-DAS1602/16
Features:
16 Single-Ended / 8 Differential Inputs 16-Bit Analog Inputs
200 kHz Throughput
2 Analog Outputs
(3) 16-Bit Down Counters
24 Digital I/O, Counter/Timer
100-Pin High Density I/O Connector
2 FIFO Buffered 16-Bit Analog Outputs with Update Rates of Up to 100 kHz
The PCI-DAS1602/16 multifunction analog and digital I/O board sets a new standard for high performance data acquisition on the PCI bus. This manual explains how to install and use the PCI-DAS1602/16 board.
The PCI-DAS1602/16 is a multifunction measurement and control board designed for the PCI bus. This board can be used for applications such as data acquisition, system timing, and industrial process control.
The PCI-DAS1602/16 board is completely plug and play, with no switches, jumpers or potentiometers to set. All board addresses and interrupt sources are set with software. You calibrate the board with software that uses programmable on-board digital potentiometers and trim D/A converters.
Analog input ranges are selectable via software as bipolar or unipolar. Bipolar input ranges are ±10 V, ±5 V, ±2.5 V and ±1.25 V. Unipolar input ranges are 0 to 10 V, 0 to 5 V, 0 to 2.5 V and 0 to 1.25 V. The PCI- DAS1602/16 has an analog trigger input. The trigger level and direction are software configurable.
The PCI-DAS1602/16 board has two 82C54 counter chips. Each chip contains three 16-bit down counters that provide clock, gate, and output connections.
