描述

PP825A 用戶可以通過該功能完成尋找機械坐標系參考點的操作

運動控制器的操作面板是一個界面友好、交互方便的設備，PP825A允許用戶以手動方式操作和監控運動軸的運動。在操作面板上，用戶可以激活或取消激活DIS輸出，選擇執行連續速度移動、查找參考點、加載參考點偏移量、重新加載當前位置等命令。此外，操作面板還可以顯示當前設備運行速度、位置和方向信息，監控到輸入、輸出點狀態信息。

操作面板是運動控制器的一個重要組成部分，PP825A用于用戶交互和控制運動軸。它友好地顯示當前設備運行速度、位置和方向信息，以及輸入、輸出點狀態信息。操作面板通常包括以下功能：
– 執行連續速度移動：用戶可以設置目標速度和目標方向，然后點擊“啟動”按鈕，使電機連續運轉。
– 執行點動操作：點擊“點動+”按鈕執行正向點動命令，點擊“點動-”按鈕執行負向點動命令，點擊時間超過0.5秒電機會加速到點動速度。
– 查找參考點：用戶可以通過該功能完成尋找機械坐標系參考點的操作。
– 執行曲線：用戶可以完成配制運動軌跡曲線的操作，并通過下拉列表選擇已組態曲線的符號名，點擊“執行”，運行指定曲線。
– 組態：用戶可以通過該功能監控、修改存儲在S7-200CPU數據塊中的配置參數信息。修改過組態設置以后，只需要先點擊“允許更新PLC中的軸組態”，再點擊“寫入”即可。

不同的運動控制器可能具有不同的操作面板設計和功能，PP825A具體操作可能因品牌和型號而異。如果你想要了解具體某一品牌或型號的運動控制器的操作面板。

PP825A 用戶可以通過該功能完成尋找機械坐標系參考點的操作

The motion controller’s operation panel is a user-friendly, interactive device, and the PP825A allows users to manually operate and monitor the motion of the motion shaft. On the operation panel, you can activate or deactivate DIS output, and choose to run commands such as continuous speed move, find reference point, load reference point offset, and reload the current position. In addition, the operation panel can also display the running speed, position, and direction of the current device, and monitor the status of the input and output points.

The operation panel is an important part of the motion controller, and the PP825A is used for user interaction and control of the motion axis. It kindly displays the current device running speed, position and direction information, as well as input and output point status information. The operation panel usually includes the following functions:
– Perform continuous speed movement: The user can set the target speed and target direction, and then click the “start” button to make the motor run continuously.
– Click the “click +” button to execute the forward click command, and click the “click -” button to execute the negative click command. If the click time exceeds 0.5 seconds, the motor will accelerate to the point speed.
– Find reference points: The user can complete the operation of finding the reference points of the mechanical coordinate system through this function.
– Execution curve: Users can complete the operation of formulating motion trajectory curves, select the symbol name of the configured curve from the drop-down list, and click “Execute” to run the specified curve.
– Configuration: Allows you to monitor and modify the configuration parameters stored in the S7-200CPU data block. After modifying the configuration Settings, just click “Allow to update the axis configuration in the PLC” and then click “Write”.

Different motion controllers may have different operating panel designs and functions, and PP825A operation may vary by brand and model. If you want to know the operation panel of a specific brand or model of motion controller.
