描述

PXIE-6556 數字波形儀

PXIE-6556是一款由美國國家儀器（National Instruments，簡稱NI）制造的200 MHz高速數字I/O模塊，具有四象限單位引腳參數測量單元（PPMU）功能。這款設備專為驗證或生產測試而設計，是一款最全面、最靈活的NI高速數字I/O模塊。

PXIE-6556模塊具有24路高速動態數據通道和4路控制通道，每路通道都具有PPMU功能。這意味著每個通道都可以獨立進行電壓等級、定時偏移和參數測量調整，從而提供精確和靈活的測試能力。此外，每個引腳的可編程電壓電平范圍在-2.0到7.0 V之間，包括VOH、VOL、VTT、VIH和VIL等，使得模塊能夠適應多種測試需求。

在性能上，PXIE-6556的每通道可高達32 mA的獨立源極或漏極電流，為測試提供了強大的電流支持。其精密的定時引擎具有亞赫茲頻率和每個引腳30 ps的定時分辨率，為測試提供了高精度的定時能力。同時，其高級ATE功能包括有源負載、較小的通道間延遲和外部SMU集成，進一步提升了測試的效率和準確性。

PXIE-6556的應用場景非常廣泛。工程師們可以利用其高達200 MHz的采樣率，產生和獲取數字波形，或在同一針腳上以1%的誤差率執行DC參數測量，從而簡化布線，減少測試時間，并提高直流參數測試儀的測量密度。此外，其內置的時序校準功能可以自動調整時序，消除不同連線與線路長度所造成的時序偏移，提高測試的準確性和穩定性。

總的來說，PXIE-6556是一款功能強大、性能卓越的200 MHz高速數字I/O模塊，具有PPMU功能，能夠滿足各種復雜的測試需求。無論是驗證、生產測試，還是其他需要精確數字I/O和參數測量的應用，PXIE-6556都能提供出色的解決方案。

PXIE-6556 數字波形儀

The PXIE-6556 is a 200 MHz high-speed digital I/O module manufactured by National Instruments (NI) with a four-quadrant unit Pin Parameter Measurement Unit (PPMU) function. Designed for validation or production testing, this device is the most comprehensive and flexible NI high-speed digital I/O module available.

The PXIE-6556 module has 24 high-speed dynamic data channels and 4 control channels, each of which has PPMU function. This means that each channel can be independently adjusted for voltage levels, timing offsets and parameter measurements, providing accurate and flexible testing capabilities. In addition, the programmable voltage levels of each pin range from -2.0 to 7.0V, including VOH, VOL, VTT, VIH, and VIL, making the module adaptable to a variety of test requirements.

In terms of performance, the PXIE-6556’s independent source or drain current of up to 32 mA per channel provides strong current support for testing. Its sophisticated timing engine has a subhertz frequency and a timing resolution of 30 ps per pin, providing high-precision timing capabilities for testing. At the same time, its advanced ATE features include active loads, small inter-channel latency, and external SMU integration, further improving the efficiency and accuracy of testing.

The PXIE-6556 is used in a wide range of applications. Engineers can take advantage of its sampling rate of up to 200 MHz, generate and acquire digital waveshapes, or perform DC parameter measurements with a 1% error rate on the same pin, simplifying wiring, reducing test time, and increasing the measurement density of DC parameter testers. In addition, its built-in timing calibration function can automatically adjust the timing, eliminate the timing offset caused by different wire and line length, improve the accuracy and stability of the test.

Overall, the PXIE-6556 is a powerful, high-performance 200 MHz high-speed digital I/O module with PPMU capabilities to meet a variety of complex test needs. Whether it’s verification, production testing, or other applications that require accurate digital I/O and parameter measurement, the PXY-6556 provides the perfect solution.
