描述

S21260-SRS 處理后的控制信號轉換為電機驅動所需的電壓和電流，從而驅動電機轉動

伺服驅動器模塊是伺服驅動器的核心組成部分，S21260-SRS伺服驅動器控制模塊通常需要高帶寬電流環路實現平滑的扭矩和速度/位置控制，通過低延遲、低位錯誤、抗EMC干擾的接口連接到編碼器、現場總線/以太網，通過高性能信號鏈處理來自編碼器/旋轉變壓器的正弦/余弦信號，以及高效、有序和受控的電壓軌，用于實現可靠運行。

伺服驅動器模塊的工作原理主要包括以下幾個方面：

信號接收與處理：S21260-SRS伺服驅動器模塊首先接收來自控制器的控制信號，這些信號通常包含電機的轉動方向、速度等指令。然后，驅動器對這些信號進行解析和處理，以確定電機的具體運動參數。
電機驅動：伺服驅動器模塊通過驅動電路對電機進行驅動。這個過程通常包括將處理后的控制信號轉換為電機驅動所需的電壓和電流，從而驅動電機轉動。
位置與速度反饋：S21260-SRS在電機轉動過程中，伺服驅動器模塊會通過編碼器等傳感器實時監測電機的位置和速度。這些信息會被反饋給控制器，形成閉環控制。
故障檢測與保護：S21260-SRS伺服驅動器模塊還具有故障檢測和保護功能。當電機或驅動器出現故障時，驅動器會及時切斷電源，防止故障擴大，同時向控制器發送故障信號，以便進行故障排除和維修。
總的來說，伺服驅動器模塊的工作原理是通過接收并處理控制信號，驅動電機轉動，同時實時監測電機的位置和速度，并將這些信息反饋給控制器，形成閉環控制。同時，它還具有故障檢測和保護功能，確保系統的穩定運行。

S21260-SRS 處理后的控制信號轉換為電機驅動所需的電壓和電流，從而驅動電機轉動

The servo driver module is the core component of the servo driver, the S21260-SRS servo driver control module usually requires a high bandwidth current loop for smooth torque and speed/position control, and connects to the encoder, fieldbus/Ethernet via low latency, low error, and EMC interference resistant interfaces. Sine/cosine signals from encoders/rotating transformers are processed through high-performance signal chains, as well as efficient, ordered and controlled voltage rails for reliable operation.

The working principle of servo driver module mainly includes the following aspects:

Signal reception and processing: The S21260-SRS servo driver module first receives the control signal from the controller, which usually contains the motor rotation direction, speed and other instructions. These signals are then analyzed and processed by the driver to determine the specific motion parameters of the motor.
Motor drive: The servo driver module drives the motor through the drive circuit. This process usually involves converting the processed control signal into the voltage and current required to drive the motor, thus driving the motor to turn.
Position and speed feedback: The S21260-SRS servo drive module monitors the position and speed of the motor in real time through sensors such as encoders during motor rotation. This information is fed back to the controller, creating a closed-loop control.
Fault detection and protection: The S21260-SRS servo drive module also has fault detection and protection functions. When the motor or driver fails, the driver will cut off the power in time to prevent the expansion of the fault, while sending a fault signal to the controller for troubleshooting and maintenance.
In general, the working principle of the servo drive module is to drive the motor by receiving and processing the control signal, while monitoring the position and speed of the motor in real time, and feeding this information to the controller to form a closed-loop control. At the same time, it also has fault detection and protection functions to ensure the stable operation of the system.
