SCXI-1193 NI RF多路復用器開關模塊 成都陽光熹禾

SCXI-1193 NI RF多路復用器開關模塊 成都陽光熹禾

  • 尺寸：1.2 x 6.8 x 7.8英寸
  • 重量：2盎司
  • 連接器：36個用于I/O連接器的MCX插孔，2個用于觸發連接器的SMB插孔
  • 工作溫度：推薦工作溫度為0°C至50°C，儲存溫度范圍為-20°C至70°C（非冷凝）
  • 最大掃描速率：每秒100次操作
分類：

描述

產品細節說明:SCXI-1193 NI RF多路復用器開關模塊

  1. 高密度設計：SCXI-1193以其高密度設計著稱，能夠在有限的空間內提供多達32個通道的切換和復用功能。
  2. 多種配置模式：該模塊支持多種配置模式，包括未端接多路復用器、外部端接多路復用器以及尺寸多樣的稀疏矩陣。這種靈活性使得SCXI-1193能夠適應不同的應用場景和測試需求。
  3. 高帶寬性能：每種配置都能承受從DC到超過500MHz的信號頻率，展現出其卓越的高頻信號處理能力。
  4. 編程可配置性：通過編程，SCXI-1193可以被配置為多種拓撲結構，如四路8 x 1多路復用器、四路4 x 1端接多路復用器、雙路16 x 1多路復用器等，以滿足各種復雜和多樣化的應用需求。
  5. 高可靠性：采用高密度推進式MCX連接器進行離散但易于管理的布線，保證了信號的穩定性和可靠性。
  6. 兼容性與集成性：SCXI-1193旨在與高頻設備集成，如PXI-5404頻率發生器和PXI-5112高速數字化儀等，進一步增強了其在高頻測試領域的應用能力。

SCXI-1193

產品詳情參數:SCXI-1193 NI RF多路復用器開關模塊

  • 尺寸：1.2 x 6.8 x 7.8英寸
  • 重量：2盎司
  • 連接器：36個用于I/O連接器的MCX插孔，2個用于觸發連接器的SMB插孔
  • 工作溫度：推薦工作溫度為0°C至50°C，儲存溫度范圍為-20°C至70°C（非冷凝）
  • 最大掃描速率：每秒100次操作

SCXI-1193 NI? 應用領域:

SCXI-1193因其高性能和靈活性，被廣泛應用于各種需要高頻信號多路復用的場景，如無線通信、雷達系統、電子戰等領域的數據采集和測試應用。SCXI-1193作為一款由NI公司制造的高密度、32通道的RF多路復用器開關模塊，以其卓越的性能、靈活的配置模式和廣泛的應用范圍，在工業自動化、通信測試、科學研究等領域發揮著重要作用。通過與其他NI產品的緊密集成，SCXI-1193能夠為用戶提供高效、準確的數據采集和測試解決方案。

Product details: SCXI-1193 NI RF multiplexer switch module
High density design: SCXI-1193 is known for its high-density design, which can provide switching and multiplexing functions for up to 32 channels in a limited space.
Multiple configuration modes: This module supports multiple configuration modes, including untested multiplexers, externally terminated multiplexers, and sparse matrices of various sizes. This flexibility enables SCXI-1193 to adapt to different application scenarios and testing requirements.
High bandwidth performance: Each configuration can withstand signal frequencies from DC to over 500MHz, demonstrating its excellent high-frequency signal processing capabilities.
Programming Configurability: Through programming, SCXI-1193 can be configured into various topology structures, such as four-way 8 x 1 multiplexer, four-way 4 x 1 terminating multiplexer, two-way 16 x 1 multiplexer, etc., to meet various complex and diverse application needs.
High reliability: The use of high-density push type MCX connectors for discrete but easy to manage wiring ensures signal stability and reliability.
Compatibility and Integration: SCXI-1193 is designed to integrate with high-frequency devices such as PXI-5404 frequency generator and PXI-5112 high-speed digitizer, further enhancing its application capabilities in the field of high-frequency testing.
Product details and parameters: SCXI-1193 NI RF multiplexer switch module
Size: 1.2 x 6.8 x 7.8 inches
Weight: 2 ounces
Connectors: 36 MCX sockets for I/O connectors, 2 SMB sockets for triggering connectors
Working temperature: Recommended working temperature is 0 ° C to 50 ° C, storage temperature range is -20 ° C to 70 ° C (non condensing)
Maximum scanning rate: 100 operations per second
SCXI-1193 NI Application Fields:

Due to its high performance and flexibility, SCXI-1193 is widely used in various scenarios that require high-frequency signal multiplexing, such as data acquisition and testing applications in wireless communication, radar systems, electronic warfare, and other fields. SCXI-1193, as a high-density, 32 channel RF multiplexer switch module manufactured by NI Corporation, plays an important role in industrial automation, communication testing, scientific research and other fields with its excellent performance, flexible configuration mode and wide application range. By tightly integrating with other NI products, SCXI-1193 can provide users with efficient and accurate data collection and testing solutions.
