SD854-3BSE088189R1 電源供應器

SD854-3BSE088189R1是一款電源供應器，它的工作原理主要可以分為四個步驟：變壓、整流、濾波和穩壓。

首先，輸入的交流電壓通過電源供應器的變壓器進行變壓。變壓器的工作原理是，當交流電壓通過其線圈時，會產生磁場，這個磁場會使得輸入電壓在變壓器的輸出線圈中感應出新的電壓。變壓器的變壓比決定了輸出電壓的大小。

接著，變壓器輸出的交流電壓進入整流電路進行整流。整流的作用是將交流電轉換為具有脈動的直流電。這個過程通常通過整流橋?qū)崿F(xiàn)，單相整流橋由四個二極管組成，而三相整流橋則需要六個二極管。

然后，整流后的直流電中還存在脈動成分，需要通過濾波電路進行濾波。濾波電路的主要任務是去除這些脈動成分，使輸出電壓更平滑。濾波可以通過電容濾波器和電感濾波器實現，電容濾波器通過將電容器連接到負載電路上來平滑輸出電壓，而電感濾波器則通過電感元件來過濾脈動成分。

最后，濾波后的直流電通過穩壓電路進行穩壓，以保持輸出電壓的穩定性。穩壓電路有兩種主要類型：線性穩壓和開關穩壓。線性穩壓器件通過調整電流流過的穩壓元件來調整輸出電壓，而開關穩壓器件則通過控制開關管的導通和截止來實現輸出電壓的穩定。

總的來說，SD854-3BSE088189R1的工作原理就是通過變壓、整流、濾波和穩壓這四個步驟，將輸入的交流電轉換為穩定、平滑的直流電，以供電子設備使用。

SD854-3BSE088189R1 電源供應器

SD854-3BSE088189R1 is a power supply, its working principle can be divided into four steps: variable voltage, rectification, filtering and voltage regulation.

First, the input AC voltage is changed through the transformer of the power supply. The transformer works by creating a magnetic field when the AC voltage passes through its coil, which induces a new voltage in the output coil of the transformer. The transformer’s transformer ratio determines the output voltage.

Then, the AC voltage output by the transformer enters the rectifier circuit for rectification. The function of rectification is to convert alternating current into direct current with pulsation. This process is usually achieved through a rectifier bridge, with a single-phase rectifier bridge consisting of four diodes and a three-phase rectifier bridge requiring six diodes.

Then, there are pulsating components in the rectified DC, which need to be filtered through the filter circuit. The main task of the filter circuit is to remove these pulsating components and make the output voltage smoother. Filtering can be achieved by capacitive filters, which smooth the output voltage by connecting capacitors to the load circuit, and inductive filters, which filter the pulsating components through inductive elements.

Finally, the filtered DC is regulated by the voltage regulator circuit to maintain the stability of the output voltage. There are two main types of voltage regulator circuits: linear regulator and switching regulator. The linear voltage regulator adjusts the output voltage by adjusting the voltage regulator through which the current flows, while the switching voltage regulator stabilizes the output voltage by controlling the on-off and off of the switching tube.

In general, the working principle of the SD854-3BSE088189R1 is to convert the input alternating current into stable and smooth direct current for electronic devices through the four steps of variable voltage, rectification, filtering and voltage regulation.
