描述

SGDV-R70A01A?? Σ-Ⅴ系列

特點
性能優異
擁有同行業中較高的放大器響應性，大大縮短了整定時間
僅為本公司以往產品的1/12

增強了振動抑制功能
通過增加和改進振動抑制功能，可提高跟隨性能，縮短整定時間。
另外還能減少驅動時的振動（音）以及停止時機械前端的振動。

與中慣量伺服電機組合，提高機械性能

起動簡便
縮短安裝時間
根據向?qū)崾?，可簡單進行參數設置
通過SigmaWin+接線確認功能,可一次性完成接線檢查。
實時跟蹤調整狀態,可瞬間完成確認。

除了起動簡便，還配備有各種便于使用的功能！
伺服電機容量選型軟件SigmaJunmaSize＋
根據用途進行適宜選型：兼顧轉動慣量、DB電阻等

調諧簡單
新型免調整功能
即使不進行伺服調整，當負載轉動慣量發生變化不超過20倍時亦可無振動地進行驅動。
整定時間：100～150ms級

新型高級自動調諧功能
在指令濾波器功能、反饋增益調整功能的基礎上，又增加了前饋增益自動調整功能，可進行適宜調整。通過摩擦補償功能，可自動平整驅動時摩擦的不規則性。
整定時間：10ms級

新型單參數調諧功能
可進行微調整，進一步提高機械性能。
整定時間：0～4ms級

維護時縮短故障診斷時間
SigmaWin＋工程工具（PC軟件）
警報診斷功能：推斷警報原因并及時提示處理方法。

SGDV-R70A01 ? ?A Σ-Ⅴ系列

peculiarity
Excellent performance
With the highest amplifier responsiveness in the industry, the setting time is greatly reduced
Only 1/12 of our previous products

Enhanced vibration suppression function
By adding and improving the vibration suppression function, the following performance can be improved and the setting time can be shortened.
In addition, it can reduce the vibration when driving (sound) and the vibration of the mechanical front end when stopping.

Combined with medium inertia servo motor to improve mechanical properties

Easy start
Reduce installation time
You can easily set parameters according to the wizard
With the SigmaWin+ Cable confirmation function, you can complete a one-time cable check.
Real-time tracking of adjustment status, can be confirmed in an instant.

In addition to easy starting, it is also equipped with a variety of easy-to-use features!
Servo motor capacity selection software SigmaJunmaSize+
Suitable selection according to the use: taking into account the moment of inertia, DB resistance, etc

Simple tuning
New adjustment free function
Even without servo adjustment, it can be driven without vibration when the load moment of inertia changes not more than 20 times.
Setting time: 100 ~ 150ms class

New advanced automatic tuning function
On the basis of the function of instruction filter and feedback gain adjustment, the function of feedforward gain automatic adjustment is added, which can be adjusted appropriately. The friction compensation function can automatically smooth the friction irregularity during the drive.
Setting time: 10ms class

New single-parameter tuning function
Micro-adjustments can be made to further improve mechanical properties.
Setting time: 0 ~ 4ms class

Shorten fault diagnosis time during maintenance
SigmaWin+ Engineering Tools (PC software)
Alarm diagnosis function: Infer the alarm cause and prompt the handling method in time.
