描述

產品細節說明：SR489-P5-LO-A20-E GE 發電機管理繼電器

• 通信和接口：
  • 后面板包括十二個RTD輸入、六個輸出繼電器、兩個RS485通信端口和四個VT輸入
  • 通信端口可以使用ModbusRTU或DNP 3.0協議（或兩者），最高可達19200 bps
  • 后面板還包括四個隔離的4-20 mA模擬輸入和輸出以及七個可分配的數字輸入
• 顯示和面板：
  • 具有一個40個字符的顯示屏，允許用戶查看值消息、診斷和設置點
  • 前面板包括多個狀態LED、輸入按鈕、數字鍵盤、輸入端口和用于讀取設備位置信息的LCD屏幕

產品詳情參數 ：SR489-P5-LO-A20-E GE 發電機管理繼電器

• 繼電器參數：
  • 相位CT次級：5A
  • 控制功率：LO控制功率為20-60 VDC，20-48 Hz時為48-62 VAC
  • 模擬輸出：4至20 mA
• 電氣參數：
  • 頻率：可在25、50或60赫茲下運行
  • 頻率參數范圍：0.00到90.00 Hz
  • 零線電壓（第3個）參數范圍：0至25000 V
  • 功率因數參數范圍：0.01至1.00超前/滯后
  • 無功功率（Mvar）參數范圍：額定電壓的-2.00至2.00倍
• 物理參數：
  • 裝運重量：約10千克
  • 尺寸：21.6厘米(長) x 22.4厘米(寬) x 25.2厘米(高)

SR489-P5-LO-A20-E GE? 應用領域：

SR489-P5-LO-A20-E適用于各種發電機管理和保護應用，能夠確保發電機的穩定運行，提高發電效率。其高可靠性、長壽命和完善的保護功能使其成為發電機保護領域的優選產品。SR489-P5-LO-A20-E是一款功能強大、易于使用的發電機管理繼電器，具有全面的保護和監視功能。其緊湊的結構、易于安裝和維護的特點，以及高可靠性和長壽命的保障，使得它在各種發電機管理和保護應用中具有廣泛的應用前景。

Product Details: SR489-P5-LO-A20-E GE Generator Management Relay
Communication and Interface:
The rear panel includes twelve RTD inputs, six output relays, two RS485 communication ports, and four VT inputs
The communication port can use Modbus RTU or DNP 3.0 protocol (or both), up to 19200 bps
The rear panel also includes four isolated 4-20 mA analog inputs and outputs, as well as seven assignable digital inputs
Display and Panel:
Featuring a 40 character display screen that allows users to view value messages, diagnostics, and setpoints
The front panel includes multiple status LEDs, input buttons, numeric keypad, input ports, and an LCD screen for reading device location information
Product details and parameters: SR489-P5-LO-A20-E GE generator management relay
Relay parameters:
Phase CT secondary: 5A
Control power: LO control power is 20-60 VDC, 48-62 VAC at 20-48 Hz
Analog output: 4 to 20 mA
Electrical parameters:
Frequency: Can operate at 25, 50, or 60 hertz
Frequency parameter range: 0.00 to 90.00 Hz
Zero line voltage (3rd) parameter range: 0 to 25000 V
Power factor parameter range: 0.01 to 1.00 lead/lag
Reactive power (Mvar) parameter range: -2.00 to 2.00 times the rated voltage

Physical parameters:
Shipping weight: approximately 10 kilograms
Size: 21.6 cm (length) x 22.4 cm (width) x 25.2 cm (height)
SR489-P5-LO-A20-E GE application areas:

SR489-P5-LO-A20-E is suitable for various generator management and protection applications, ensuring stable operation of generators and improving power generation efficiency. Its high reliability, long lifespan, and comprehensive protection functions make it the preferred product in the field of generator protection. SR489-P5-LO-A20-E is a powerful and easy-to-use generator management relay with comprehensive protection and monitoring functions. Its compact structure, easy installation and maintenance, as well as high reliability and long lifespan guarantee, make it widely applicable in various generator management and protection applications.
