描述

VMIACC-5595-208-350-805595-208L 2 Gb/s 反射內存集線器組件

部件編號VMIACC-5595-208
?外殼:機架安裝或桌面
?單模(10km)可插拔收發器數量:0
?多?？刹灏问瞻l(fā)器數量:8個

部件編號:350-805595-208E, 350-805595-208H, 350-805595-208J

特點:
使用小尺寸可插拔收發器提供多達8個端口
自動繞過有缺陷或斷開連接的節點
每個端口再生串行光信號
可配置電纜長達10公里的長度
GE Fanuc / VMIC VMIACC-5595 Gb/s反射存儲器集線器組件是一個托管集線器，旨在與GE Fanuc / VMIC 5565系列反射存儲器實時網絡產品一起運行。反射內存集線器可以在檢測到信號丟失或有效同步模式丟失時自動繞過端口，從而允許網絡中的其他節點保持運行。由于光端口采用SFP (small form factor pluggable)收發器，因此只需要填充所需的端口。VMIACC-5595 SFP光模塊可以是多模(短距離)或單模(長距離)光模塊的組合。該特性允許在小型網絡中節省成本并優化系統。對于較大的網絡，幾個VMIACC-5595組件可以級聯，允許最多256個節點的托管集線器陣列。每個端口再生串行光信號，消除了插入損耗和電纜衰減的問題。信號再生也減少了抖動。RS232端口提供了通過簡單的PC串口監控和控制反射存儲器網絡的能力。以太網端口功能允許用戶通過局域網(LAN)或Web瀏覽器遠距離監視和控制集線器

VMIACC-5595可配置為19英寸1U機架式插框或桌面插框。通用電源允許幾乎任何國際電源標準的操作。

當檢測到沒有有效的同步模式時，VMIACC-5595會自動繞過端口。三個led，相鄰每個端口，提供端口狀態的視覺指示。其他狀態指示和操作模式可通過串行端口或以太網端口獲得。

狀態信息包括已安裝收發器的檢測、信號(光)的檢測、有效同步模式的檢測、端口運行速度(2Gb/s)?？刂萍拇嫫髟试S在沒有單一有效同步模式或多個同步模式的情況下繞過通道。旁路也可以簡單地基于信號(光)的損失。此外，無論狀態指示燈如何，每個端口都可以手動強制激活或繞過。

VMIACC-5595-208-350-805595-208L 2 Gb/s 反射內存集線器組件

Part Number VMIACC-5595-208
? Enclosure: Rack Mount or Desktop
? Number of Single-Mode (10km) Pluggable Transceivers: 0
? Number of Multimode Pluggable Transceivers: 8

Part Numbers: 350-805595-208E, 350-805595-208H, 350-805595-208J

Features:
Provides up to Eight Ports Using Small Form Factor Pluggable Transceivers
Automatically Bypasses Defective or Disconnected Nodes
Each Port Regenerates the Serial Optical Signal
Configurable for Cables up to 10 km in Length
The GE Fanuc / VMIC VMIACC-5595 Gb/s Reflective Memory Hub Assembly is a managed hub designed to operate with the GE Fanuc / VMIC 5565 family of Reflective Memory real-time network products. The Reflective Memory hub can automatically bypass ports when it detects a loss of signal or the loss of valid synchronization patterns, allowing the other nodes in the network to remain operational. Since the optical ports are implemented with small form factor pluggable (SFP) transceivers, only the required ports need to be populated. The VMIACC-5595 SFP transceivers can be a combination of either multimode (short distance) or single-mote (long-distance) transceivers. This feature permits a cost saving in small networks as well as system optimization. For larger networks, several VMIACC-5595 assemblies can be cascaded, permitting a managed hub aray with up to 256 nodes. Each port regenerates the serial optical signal, eliminating the problems with insertion losses and cable attenuation. Signal regeneration also reduces jitter. The RS232 port gives the ability to monitor and control the Reflective Memory network through a simple PC serial port. The Ethernet port feature allows the user to monitor and control the hub from great distances through a local area network (LAN) or via a Web browser

The VMIACC-5595 can be configured as a 19-inch 1U rack-mountable enclosure or as a desktop enclosure. The universal power supply permits operation with nearly any international power standard.

The VMIACC-5595 automatically bypasses ports when the absence of valid synchronization patterns is detected. Three LEDs, adjacent to each port, provide a visual indication of the port status. Additional status indications and modes of operation are available through either the serial port or the Ethernet port.

Status information includes the detection of installed transceivers, the detection of signal (light), the detection of valid synchronization patterns, and the port operation speed (2Gb/s). Control registers allow the channel bypass to be based on the absence of a single valid synchronization pattern or multiple synchronization patterns. A bypass can also be based simply on the loss of a signal (light). In addition, each port can be manually forced either active or bypassed regardless of the status indicators.
