描述

VMIVME-5565-110000332-015565-110000-P–VME-5565 主要特點是其嚴格的傳輸確定性和可預測性

反射內存節點卡（RMN Reflective Memory Network）是一種高速的實時網絡，VMIVME-5565-110000332-015565-110000-P–VME-5565允許采用不同的總線結構和不同的操作系統的計算機以確定的速率分享實時數據。這種網絡的主要特點是其嚴格的傳輸確定性和可預測性，以及高速、主機負載輕、軟硬兼容性強、易于使用、可靠的傳輸糾錯能力和支持中斷信號傳輸?shù)取?/p>

反射內存節點卡是一種PCI設備，提供給用戶128MB的讀寫空間。當網絡中的一個節點有寫入操作時，這個操作會自動通過光纖鏈路將數據同步到所有其他節點。這一系列的傳輸寫入操作是由硬件完成的，因此兩個節點間的更新延時可以達到100ns級。此外，該節點卡支持光纖傳輸，節點與節點之間的傳輸時間通常為1微秒，對于擁有30個節點的系統，通過網絡傳輸?shù)剿泄?jié)點的時間只需30微秒，而且節點之間的距離可以達到10公里。

在硬件層面，VMIVME-5565-110000332-015565-110000-P–VME-5565反射內存節點卡的工作流程是：當數據需要寫入時，數據首先被寫入到SDRAM中，同時數據、地址和控制數據會被打包發送到發送FIFO。在這個過程中，SERDES會在接收到FIFO數據的中斷后，立即將FIFO的數據讀取并轉換為串行數據，然后通過光纖收發器發送出去。這個過程的FIFO讀取時間只需要大約4個周期。

總的來說，VMIVME-5565-110000332-015565-110000-P–VME-5565反射內存節點卡是一種高性能、高可靠性的實時數據傳輸設備，適用于需要高速、確定性和可靠性的各種應用場景，如工業自動化、能源管理、醫療設備等領域。

VMIVME-5565-110000332-015565-110000-P–VME-5565 主要特點是其嚴格的傳輸確定性和可預測性

RMN Reflective Memory Network (RMN Reflective Memory Network) is a high-speed real-time network. VMIVME-5565-11000033 2-015565-11010000-p -VME-5565 allows computers with different bus structures and different operating systems to share real-time data at a determined rate. The main characteristics of this network are its strict transmission certainty and predictability, as well as high speed, light host load, strong soft and hard compatibility, easy to use, reliable transmission error correction ability and support for interrupt signal transmission.

The reflected memory node card is a PCI device that provides the user with 128MB of read and write space. When a node in the network has a write operation, this operation automatically synchronizes data to all other nodes through the fiber link. This series of transmission write operations is done by the hardware, so the update delay between the two nodes can reach 100ns. In addition, the node card supports fiber optic transmission, the transfer time between nodes is usually 1 microsecond, for a system with 30 nodes, the time to transfer through the network to all nodes is only 30 microseconds, and the distance between nodes can reach 10 kilometers.

At the hardware level, VMIVME-5565-11000033 2-015565-11010000-p — The working process of the VME-5565 reflected memory node card is that when data needs to be written, the data is first written to SDRAM and at the same time the data, address and control data are packaged and sent to the sending FIFO. In this process, the SERDES will immediately read and convert the FIFO data into serial data after receiving the interruption of the FIFO data, and then send it out through the optical fiber transceiver. The FIFO read time for this process only takes about 4 cycles.

In general, the VMIVME-5565-11000033 2-015565-11010000-P — The VME-5565 Reflective memory node card is a high performance and high reliability real-time data transmission device suitable for a variety of application scenarios that require high speed, certainty and reliability. Such as industrial automation, energy management, medical equipment and other fields.
