描述

VT-MACAS-500-10V0I 模擬位置控制器

VTMACAS50010V0
模擬位置控制器
13個終端
4-20MA
24伏直流電
放大器是一個電子控制單元，適用于開環比例閥。控制器的輸出電流與參考信號成正比，與溫度變化和負載阻抗無關。比例電磁鐵采用PWM供電，可以減小閥的磁滯，提高控制精度。在前面板上安裝了一個可調的電位器，用于參數設置，以提高系統性能。放大器有三種型號，用于單電磁比例閥，雙電磁比例閥和單電磁比例閥，具有雙通道控制。每種類型的電子控制單元都有不同的大電流和開關頻率(PWM)，可以根據所使用的閥門類型(PWM)進行選擇。
控制電壓可以直接施加到控制輸入1，也可以借助電源的9v調節電壓，通過外部控制值電位器施加到控制輸入1
供應設備。對于這個輸入，以下是有效的:9v ?1)控制值輸入2為差分輸入(0 ~ 10v)，帶DIL開關2)，可配置電流輸入(4 ~ 20ma或0 ~ 20ma)。如果控制值由具有不同參考電位的外部電子元件前饋(例如，通過PLC)，則必須使用該輸入。當施加或去除控制電壓時，必須小心地從輸入端斷開或連接兩根信號電纜。

VT-MACAS-500-10V0I 模擬位置控制器

VTMACAS50010V0
Analog position controller
13 Terminal
4-20MA
24 volts direct current
The amplifier is an electronic control unit suitable for open-loop proportional valves. The controller’s output current is proportional to the reference signal and independent of temperature changes and load impedance. Proportional electromagnet using PWM power supply, can reduce the magnetic hysteresis of the valve, improve the control accuracy. On the front panel, an adjustable potentiometer for parameter setting is installed to improve system performance. The amplifer is available in three models for single-solenoid proportional valves, dual-solenoid proportional valves, and single-solenoid proportional valves with dual-channel control. Each type of electronic control unit has different high current and switching frequency (PWM), which can be selected according to the type of valve used (PWM).
The control voltage can be applied to the control input 1 directly or via an external control value potentiometer with the help of the 9 V regulation voltage of the power
supply device. For this input, the following is valid: 9 V? 100% 1) Control value input 2 is a differential input (0 to 10 V). With DIL switch 2), it can be configured for current input (4 to 20 mA or 0 to 20 mA). This input must be used if the control value is fed forward by an external electronic component with a different reference potential (for example, via a PLC). When applying or removing the control voltage, care must be taken to disconnect or connect the two signal cables from the input.
