描述

133388-01 架組態并調出機組中信息的專有協議

框架接口模塊(RIM)是3500框架的基本接口。它支持本特利用于框架組態并調出機組中信息的專有協議。框架接口模塊必須放在框架中的第一個槽位(緊靠電源的位置)。?RIM?可以與兼容的本特利通訊處理器，如TDXnet、TDIX?和DDIX?等連接。雖然RIM?為整個框架提供某些通用功能，但它并不是重要監測路徑中的一部分，對整個監測系統的正確和正常運行沒有影響。每個框架需要一個框架接口模塊。

其前面板上有RS-232?串行接口，可以與主機連接進行數據采集和框架組態，波特率最大38.4K，電纜長度要求最長30m。后面的I/O（輸入/輸出）模塊上有?RS-232/RS-422?串行接口，同樣可以與主機連接進行數據采集和框架組態，最大波特率38.4K，電纜長度：RS232為最長30m，RS422為最長1200m。RS422接口還能使使多臺3500框架以鏈連接同3500?主機軟件進行通訊。

超速檢測模塊是一種用于檢測設備或車輛速度的裝置，通常與控制電路、報警系統等一起使用，用于監控設備或車輛的速度是否超過預設的限制。

超速檢測模塊可以通過不同的方式進行檢測，如通過測量設備旋轉部件的轉速、通過測量車輛行駛的距離和時間等。當設備或車輛的速度超過預設的限制時，超速檢測模塊會觸發報警系統或其他控制電路，以提醒操作人員或自動采取相應的措施，如減速或停車等。

超速檢測模塊廣泛應用于各種需要防止超速的場合，如工業自動化、交通運輸?shù)阮I(lǐng)域。例如，在交通運輸領域，超速檢測模塊可以用于高速公路、火車、飛機等交通工具上，用于檢測車輛或飛機的速度，防止超速行駛。

總之，超速檢測模塊是一種重要的安全裝置，可以有效地防止設備或車輛超速行駛，保障人身和財產安全。

133388-01 架組態并調出機組中信息的專有協議

The Framework Interface Module (RIM) is the basic interface of the 3500 framework. It supports Bent’s proprietary protocols for framing and retrieving information from the unit. The frame interface module must be placed in the first slot in the frame (next to the power supply). RIM can connect with compatible Bentley communication processors such as TDXnet, TDIX, and DDIX. Although RIM provides some common features for the entire framework, it is not part of the critical monitoring path and has no impact on the correct and normal operation of the overall monitoring system. Each framework requires a framework interface module.

There is a RS-232 serial interface on the front panel, which can be connected with the host for data acquisition and frame configuration, the baud rate is up to 38.4K, and the cable length is required to be up to 30m. The rear I/O (input/output) module has a RS-232/RS-422 serial interface, which can also be connected with the host for data acquisition and frame configuration, the maximum baud rate of 38.4K, the cable length: RS232 is the longest 30m, RS422 is the longest 1200m. The RS422 interface also enables multiple 3500 frames to communicate with the 3500 host software in a chain connection.

Speed detection module is a device used to detect the speed of equipment or vehicles, usually used in conjunction with the control circuit, alarm system, etc., to monitor whether the speed of equipment or vehicles exceeds the preset limit.

The overspeed detection module can be detected in different ways, such as by measuring the speed of the rotating parts of the equipment, by measuring the distance and time of the vehicle. When the speed of the device or vehicle exceeds the preset limit, the speed detection module will trigger the alarm system or other control circuits to alert the operator or automatically take corresponding measures, such as slowing down or stopping.

The overspeed detection module is widely used in various occasions that need to prevent overspeed, such as industrial automation, transportation and other fields. For example, in the field of transportation, the speed detection module can be used on highways, trains, planes and other vehicles to detect the speed of vehicles or aircraft and prevent speeding.

In short, the speed detection module is an important safety device, which can effectively prevent equipment or vehicles from speeding and ensure personal and property safety.
