1756-OB16D ControlLogix 16 Pt 24V直流D/O模塊

Allen-Bradley 1756-0B1 6D是一個ControlLogix DC診斷輸出模塊.它有1 6個診斷輸啊用，每組8個點子融合以每分為基礎。您可以將安裝在兼容ControlLogix機箱中的任何可用插槽中。但是，為此需要一個36位可拆卸接線 盒外殼(RTB)。RTB可以是1756年的TBCH或者1756年的TBS6H.在安裝帶有RTB的模塊之前，務必將機箱和電源安裝并接地。

這款1756-0B1 6D模塊與其他輸出模塊具有以下共同特征:輸出數據回聲、多輸出點密度、可配置點級輸出狀態、電子熔斷以及隔離和非隔離輸出模塊。它還允許您配置模塊的各種功能，特別是空載檢測、輸出驗證檢測、故障模式下的輸出狀態、程序模式下的輸出狀態、從程序狀態到故障狀態的轉換以及診斷鎖存。

的短行程診斷功能1756-0B1 6D模塊180毫秒(最小)時為8安，120毫秒(最小)時為10安。 空載功能僅用于關斷狀態檢測，輸出驗證僅用于導通狀態檢測。脈沖測試具有用戶可配置的最大脈沖寬度。該模塊還允許您配置每個點的故障狀態和每個點的程序模式狀態，其中默認設置為”關”，其他選項為“開” 和“保持最后狀態”這個輸出模塊擁有19.2至30伏DC的工作電壓范圍和24伏DC電源電壓類別.它還具有每點3 mA的最小負載電流、每點1 mA的最大關態漏電流和1.2V的DC(最大導通壓降為2 A)。其背板電流在24V DC時為140 mA,在5.1V DC時為250 mA,背板總功率為4.64 W。其線性降額輸出電流額定值在30攝氏度(80華氏度)時最大為2 A,在60攝氏度(140華氏度)時每點最大為1 A,每個模塊的額定值在30攝氏度時最大為8 A,在60攝氏度時最大為4A。每點的浪涌電流1756-0B1 6D每個10 ms的模塊為4A,每秒可重復-次。其組與組和用戶與系統之間的隔離電壓在2546V下測試了1秒，兩者的最大持續交流電壓均為250V。

它的輸出延遲時間標稱值為55s，從關到開最長為1 ms,標稱值為630 s,從開到關最長為5 ms。工作溫度范圍為0至60攝氏度(32至140華氏度),儲存溫度為- 40至85攝氏度( 40至185華氏度)。

1756-OB16D ControlLogix 16 Pt 24V直流D/O模塊

Allen-Bradley 1756-0B1 6D is a ControlLogix DC diagnostic output module. It has 16 diagnostic inputs, each group of 8 points fused on the basis of each score. You can install it in any available slot in a Controllogix-compatible chassis. However, a 36-bit detachable wiring box housing (RTB) is required for this purpose. The RTB can be TBCH of 1756 or TBS6H of 1756. Before installing a module with RTB, ensure that the chassis and power supply are installed and grounded.

The 1756-0B1 6D module shares the following characteristics with other output modules: output data echo, multiple output point density, configurable point level output states, electronic fusing, and isolated and non-isolated output modules. It also allows you to configure various functions of the module, especially no-load detection, output verification detection, output state in fault mode, output state in program mode, transition from program state to fault state, and diagnostic latches.

The short stroke diagnostic function of the 1756-0B1 6D module is 8 amps at 180 ms (minimum) and 10 amps at 120 ms (minimum). The no-load function is only used for off status detection, and the output verification is only used for on-status detection. The pulse test has a user-configurable maximum pulse width. The module also allows you to configure the fault state of each point and the program mode state of each point, where the default is set to “off” and the other options are “On” and “Hold Last” This output module has an operating voltage range of 19.2 to 30 volts DC and a 24 volt DC supply voltage category. It also has A minimum load current of 3 mA per point, a maximum off-state leakage current of 1 mA per point and a DC of 1.2V (with a maximum on-voltage drop of 2 A). The backplane current is 140 mA at 24V DC, 250 mA at 5.1V DC, and the total backplane power is 4.64W. Its linear derated output current ratings are up to 2 A at 30 degrees Celsius (80 degrees Fahrenheit), 1 A per point at 60 degrees Celsius (140 degrees Fahrenheit), and 8 A per module at 30 degrees Celsius and 4A at 60 degrees Celsius. The surge current at each point 1756-0B1 6D is 4A for each 10 ms module and can be repeated – times per second. The isolation voltage between the group and the user and the system was tested for 1 second at 2546V, with a maximum continuous AC voltage of 250V for both.

It has a nominal output delay time of 55s, a maximum of 1 ms from off to on, a nominal value of 630 s, and a maximum of 5 ms from on to off. Operating temperatures range from 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit) and storage temperatures from -40 to 85 degrees Celsius (40 to 185 degrees Fahrenheit).
