2094-BC04-M03-SC Allen-Bradley Kinetix 6000驅動系統模塊

2094- BC04-M03-S是一個Kinetix 6000驅動系統模塊。該組件由Allen-Bradley制造,設計用作變頻器的集成軸模塊。該模塊的額定輸出功率在20%負載時為53瓦，40%負載時為72瓦，60%負載時為93瓦，80%負載時為116瓦， 100%負載時為142瓦。

該模塊有一個轉換器和逆變器部分。轉換器部分的輸出額定值為28kW,逆變器為30安培。該模塊也稱為AM電源模塊。它配有用于電機電源(MP)和電機/電阻制動電源(BC)的接線插頭連接器。該模塊不提供目錄號為2090-K6CK-D44M和2090-K6CK-D44S0的連接器套件輸入和輸出接口、安全和輔助反饋信號以及目錄號為2090-K6CK-D15M的電機反饋。

使用該模塊時，并不總是需要接地跳線設置。然而，不接地或高阻抗電源配置需要接地跳線設置。要設置接地跳線設置,請從電源軌上卸下集成訪問模塊(IAM ),打開電源模塊并將跳線位置修改到適當?shù)奈恢?。默認情況下，模塊設置為接地位置，其中P1 6和P17短路，而未接地配置的P18和P19端子短路。

安裝2094-BC04-M03-S時，首先安裝集成安訊士模塊，然后安裝IPIM、安訊士模塊、分流模塊和插槽填充模塊。IAM必須安裝在電源軌的最左側。
其他模塊位于IAM的右側。

2094-BC04-M03-SC Allen-Bradley Kinetix 6000驅動系統模塊

The 2094-BC04-M03-S is a Kinetix 6000 drive system module. The assembly was manufactured by Allen-Bradley and designed to be used as an integrated shaft module for a frequency converter. The rated output power of the module is in
At 20% load it is 53 watts, at 40% load it is 72 watts, at 60% load it is 93 watts, at 80% load it is 116 watts and at 100% load it is 142 watts.

The module has a converter and inverter section. The output rating of the converter section is 28kW and the inverter is 30 amps. This module is also called an AM power module. It comes with a power supply (MP) for motors and
Plug connector for motor/resistance brake power supply (BC). The module does not provide connector kit input and output interfaces, safety and security for catalog numbers 2090-K6CK-D44M and 2090-K6CK-D44S0
Auxiliary feedback signal and motor feedback with catalog number 2090-K6CK-D15M.

When using this module, it is not always necessary to ground jumper Settings. However, ungrounded or high-impedance power supply configurations require ground jumper Settings. To set the ground jumper Settings, remove the Integrated Access Module (IAM) from the power rail, turn on the power module and change the jumper position to the appropriate position. By default, the module is set to the ground position, where P6 and P17 are short-circuited, while the ungrounded terminals P18 and P19 are short-circuited.

When installing the 2094-BC04-M03-S, install the integrated Axis module first, followed by the IPIM, Axis module, shunt module, and slot fill module. The IAM must be installed on the leftmost side of the power rail.
Other modules are on the right of IAM.
