20-750-POD1-F8 增星式編碼器模塊

Allen-Bradley 20-750-POD1-F8是一種增星式編碼器模塊，用于兼容PowerHlex 753、PowerHlex 755、PowerHlex755TL和PowerFHlex755TR可調頻率交流驅動器。該編碼器模塊提供了實現環路定位控制的能力，這是PowerFlex700類驅動器支持的控制能力之一。

該編碼器模塊特別適合安裝在框架A驅動的PowerHlex 753端口4和5中;以及用于框架2和更高驅動器的端口4、5和6。它也可以與Powerflex755驅動器—起使用，并安裝到框架1驅動器的端口4和5以及PowerFHlex框架2和更高驅動器的端口4、5、6和7。如果與PowerHlex755T—起使用，它可以安裝在第5-15幀媽區動器的端口4、5、6、7和8中。

20-750-POD1-F8支持單端或差分操作。它具有恒定吸電流操作，功耗約為10 mA。這些模塊的輸入電壓范圍為5VDC-15VDC，源電流消耗為10mA。編碼器通道的最小高態電壓為3.5VDC，最大低態電壓為0.4 VDC。連接到編碼器模塊的電線在5V時不得超過30米(100英尺)，在12V時不得超過183米(600英尺)。它與開關頻率為250 kHz的輸入設備兼容。該編碼器模塊支持驅動器供電和單獨供電的編碼器電源配置。它有一個TB1端子，由14個引腳組成，用于信號和電源電壓布線。

20-750-POD1-F8 增星式編碼器模塊

Allen-Bradley 20-750-POD1-F8 is an augmented star encoder module for compatibility with PowerHlex 753, PowerHlex755, PowerHlex755TL, and PowerFHlex755TR tunable frequency AC drives. The encoder module provides the ability to implement loop positioning control, one of the control capabilities supported by PowerFlex700 class drives.

The encoder module is particularly suitable for installation in PowerHlex 753 ports 4 and 5 driven by frame A; And ports 4, 5, and 6 for Frame 2 and higher drives. It can also be used with Powerflex755 drives – and installed to ports 4 and 5 of Frame 1 drives and ports 4, 5, 6 and 7 of PowerFHlex frame 2 and higher drives. If used with PowerHlex755T -, it can be installed in ports 4, 5, 6, 7 and 8 of the frame 5-15 motor.

20-750-POD1-F8 supports single-ended or differential operation. It has constant current absorption operation and a power consumption of about 10 mA. These modules have an input voltage range of 5VD-15VDC and a source current consumption of 10mA. The encoder channel has a minimum high-state voltage of 3.5VDC and a maximum low-state voltage of 0.4 VDC. The wire connected to the encoder module must not exceed 30 meters (100 ft) at 5V and 183 meters (600 ft) at 12V. It is compatible with input devices with a switching frequency of 250 kHz. The encoder module supports both driver powered and individually powered encoder power configurations. It has a TB1 terminal consisting of 14 pins for signal and supply voltage wiring.
