330130-085-00-05 延伸電纜有帶鎧裝和不帶鎧裝兩種類型

330130-085-00-05延伸電纜是指連接探頭和前置器的中間部件，其安裝應保證在使用過程中不易受到損壞，信號傳輸正?？煽?。以下是延伸電纜的應用場景和注意事項：

應用場景：
管道鋪設：通常不帶鎧裝的延伸電纜采用管道鋪設，若采用帶鎧裝的延伸電纜，需確保管道鋪設時不會損壞電纜。
設備連接：延伸電纜用于連接傳感器探頭和前置器，通常需要保證信號傳輸?shù)目煽啃院头€(wěn)定性。

注意事項：
信號傳輸：在安裝過程中，應保證延伸電纜的接頭與信號“地”相聯接，且接頭金屬表面應裸露，同時為了避免聯接處和機殼接觸，通常將延伸電纜與探頭電纜相聯的一端帶有絕緣保護套。

電纜長度：在選型時，應保證延伸電纜的長度加探頭電纜的長度之和，大于探頭安裝處到前置器安裝處的距離。

固定與防護：過長的電纜應盤成直徑不小于50mm的圓形并用綁帶扎緊后固定，不能隨意剪斷或加長電纜，否則會造成傳感器系統特性的變化。

選型與安裝：延伸電纜有帶鎧裝和不帶鎧裝兩種類型，在選型時需根據實際應用場景選擇合適的類型。在安裝時，應將延伸電纜接頭與探頭高頻接頭用手?jǐn)Q緊聯接好，然后將套管套在接頭處，起到絕緣和保護作用。

330130-085-00-05 延伸電纜有帶鎧裝和不帶鎧裝兩種類型

330130-085-00-05 Extension cable refers to the middle part connecting the probe and the preprocessor, and its installation should ensure that it is not easy to be damaged during use, and the signal transmission is normal and reliable. The following are the application scenarios and precautions for extension cables:

Application scenario:
Laying pipes: Generally, unarmoured extension cables are laid through pipes. If armoured extension cables are used, ensure that the cables are not damaged during laying.
Device connection: Extension cables are used to connect sensor probes and precursors, usually to ensure the reliability and stability of signal transmission.

Note:
Signal transmission: During the installation process, it should be ensured that the connector of the extension cable is connected to the signal “ground”, and the metal surface of the connector should be exposed, and in order to avoid contact between the connection and the housing, the end of the extension cable and the probe cable are usually connected with an insulating protective sleeve.

Cable length: In the selection, it should be ensured that the sum of the length of the extended cable plus the length of the probe cable is greater than the distance between the probe installation and the preloader installation.

Fixed and protection: too long cable should be coiled into a circle with a diameter of not less than 50mm and fixed after binding, do not cut or extend the cable at will, otherwise it will cause changes in the characteristics of the sensor system.

Selection and installation: There are two types of extension cables with and without armor. Select an appropriate type based on the actual application scenario. During installation, the extension cable joint and the probe high-frequency joint should be tightly connected by hand, and then the sleeve is placed on the joint to provide insulation and protection.
