描述

6181P-15TPXPSS 投射式電容觸摸屏

618p – 15tpxpss VersaView 1500P集成顯示計算機是一款堅固耐用的工業計算機，具有集成顯示和不銹鋼邊框，設計用于工廠環境，用于許多自動化工業應用的視覺界面，控制和維護。它提供12.1英寸彩色有源矩陣，薄膜晶體管，平面觸摸顯示屏，顯示面積為12英寸x 9英寸，本機分辨率為1024 x 768, 16.7米顏色。6181P-15TPXPSS分別提供垂直和水平40度和600度的角度視圖，并且計算機具有15ms的最小顯示響應時間。它有一個英特爾酷睿雙核U2500處理器，處理器速度為1.2 GHz，內存為2M L2高速緩存。它還具有雙通道DDR2內存插槽，最大安裝內存為4GB，它還具有2個PCI插槽，可升級為1個PCI插槽加1個PCI Express插槽。這臺電腦有2個(1個可啟動，1個可熱插拔)緊湊型閃存插槽，安裝了一個40GB的2.5英寸SATA旋轉硬盤驅動器，并配有一個超薄DVD-RW/CD-RW驅動器。

6181P-15TPXPSS有1個PS/2鼠標/鍵盤端口，1個并口，1個DVI-I端口，4個后置USB端口，2個串行COM端口，一個音頻線輸入/輸出，一個麥克風插槽，和一個2GB以太網/IP LAN端口。它的工作溫度范圍為0-55℃(32-131 of)，非冷凝相對濕度范圍為10-90%，存儲溫度范圍為-20-60℃(-4-140 of)。該計算機具有NEMA類型1,4,12和IEC ip66等級外殼，可承受15G的沖擊和57-640Hz的1G振動。它的平均重量為10.7公斤(23.6磅)，尺寸約為309毫米x 410毫米x 100毫米(12.16英寸x 16.14英寸x 3.94英寸)，它可以在高達6,561英尺的高度上正常工作。

6181P-15TPXPSS 投射式電容觸摸屏

The 6181P-15TPXPSS VersaView 1500P Integrated Display Computer is a rugged industrial computer with an integrated display and a stainless-steel bezel designed for use in a factory environment for the visual interface, control, and maintenance of many automated industrial applications. It offers a 12.1in color active matrix, thin film transistor, flat touch display screen, with a 12in x 9in display area and a native resolution of 1024 x 768 in 16.7M colors. The 6181P-15TPXPSS provides an angular view of 40 o and 60o vertical and horizontal, respectively, and the computer has a minimum display response time of 15ms. It has an Intel Core Duo U2500 Processor with 1.2 GHz of processor speed and a 2M L2 cache memory. It also has a dual-channel DDR2 memory slot with 4GB maximum of installed memory, and it also has 2 PCI slots that are upgradable to 1 PCI slot plus 1 PCI Express slot. The computer has 2 (1 bootable, and 1 hot-swappable) compact flash memory slots, with a 40GB 2.5in SATA rotating hard disk drive installed, and it comes with a Slim DVD-RW/CD-RW Drive.

The 6181P-15TPXPSS has 1 PS/2 mouse port/keyboard port, 1 Parallel port, 1 DVI-I port, 4 rear USB ports, 2 serial COM ports, an Audio line in/line out, a Microphone slot, and a 2GB Ethernet/IP LAN port. It has a working temperature range of 0-55 oC (32-131 oF), at 10-90% non-condensing relative humidity range, and it can be stored at a range of -20-60 oC (-4-140 oF). The computer has a NEMA Type 1, 4, 12, and IEC IP66-rated enclosure, and it is built to resist a shock of 15G and a vibration of 1G at 57-640Hz. It weighs averagely 10.7kg (23.6lb), with approximate dimensions of 309mm x 410mm x 100mm (12.16in x 16.14in x 3.94in), and it can function without de-rating at an altitude of up to 6,561 feet.
