ABB 216DB61 HESG324063R100/H 數字輸入/輸出模塊

The ABB 216DB61 HESG324063R100/H is a multifunctional Module for industrial automation and control systems produced by ABB. Specifically, it is a Digital Input/Output Module.
ABB 216DB61 HESG324063R100/H 是一款由 ABB 公司生產的工業自動化和控制系統中的多功能模塊，具體來說，它是一款 數字輸入/輸出模塊（Digital Input/Output Module）。

This module is widely used in ABB’s AC 500 series PLC systems to achieve signal acquisition and control functions in industrial sites.
該模塊廣泛應用于 ABB 的 AC 500 系列 PLC 系統中，用于實現工業現場的信號采集與控制功能。

Product Overview
產品概述

The ABB 216DB61 HESG324063R100/H is a high-performance industrial automation component, specifically designed for industrial automation systems and supporting the control and monitoring of various industrial processes.
ABB 216DB61 HESG324063R100/H 是一款高性能的工業自動化組件，專為工業自動化系統設計，支持多種工業過程的控制和監控。

This module is based on a modular architecture, allowing for flexible configuration and customization to meet the needs of different application scenarios.
該模塊基于模塊化架構，允許靈活配置和定制，以滿足不同應用場景的需求。

It can provide precise and reliable control and is suitable for various industrial processes such as temperature, pressure, flow and liquid level.
它能夠提供精確可靠的控制，適用于溫度、壓力、流量和液位等多種工業過程。

Product features
產品特點

Versatility: This module integrates 16 digital input channels and 16 digital output channels, reducing the need for individual input/output units and optimizing the space within the control cabinet.
多功能性：該模塊集成了 16 個數字輸入通道和 16 個數字輸出通道，減少了對單獨輸入/輸出單元的需求，優化了控制柜內的空間。

High reliability: The module is designed for industrial environments and features excellent anti-interference ability and stability, ensuring reliable operation under complex working conditions.
高可靠性：模塊設計用于工業環境，具有良好的抗干擾能力和穩定性，確保在復雜工況下的可靠運行。

Communication capability: Supports multiple communication protocols, such as Profibus DP, CANopen, etc., facilitating data exchange with the host computer or other devices.
通信能力：支持多種通信協議，如 Profibus DP、CANopen 等，便于與上位機或其他設備進行數據交換。

Easy to install and maintain: The module adopts a standard DIN rail installation method, which is convenient for installation and maintenance.
易于安裝和維護：模塊采用標準的 DIN 導軌安裝方式，便于安裝和維護。

Protection function: Each channel is equipped with short-circuit and overload protection functions to ensure the safe operation of the module in harsh environments.
保護功能：每個通道都具備短路和過載保護功能，確保模塊在惡劣環境下的安全運行。

Technical specifications
技術規格

Model: 216DB61 HESG324063R100-H
型號：216DB61 HESG324063R100-H

Manufacturer: ABB
制造商：ABB

Product type: Digital input/output module
產品類型：數字輸入/輸出模塊

Input channel: 16 (24V DC, source type/drain type)
輸入通道：16（24V DC，源型/漏型）

Output channels: 16 (24V DC, 2A per channel)
輸出通道：16（24V DC，每通道 2A）

Communication protocols: Profibus DP, CANopen
通信協議：Profibus DP、CANopen

Physical dimensions: 100mm (width) × 101mm (height) × 50mm (depth)
物理尺寸：100 mm（寬）× 101 mm（高）× 50 mm（深）

Weight: 0.3 kg
重量：0.3 kg

Power supply voltage: 24V DC (±20%)
電源電壓：24V DC（±20%）

Operating temperature: -25°C to +60°C
工作溫度：-25°C 至 +60°C

Humidity range: 5% to 95% (no condensation)
濕度范圍：5% 至 95%（無冷凝）

Installation method: DIN rail (TS 35/7.5 or TS 35/15)
安裝方式：DIN 導軌（TS 35/7.5 或 TS 35/15）

Application field
應用領域

ABB 216DB61 HESG324063R100/H is widely used in industrial automation systems, especially in the following fields:
ABB 216DB61 HESG324063R100/H 廣泛應用于工業自動化系統，特別是在以下領域：

Industrial automation: It is used to control and monitor various industrial equipment and systems.
工業自動化：用于控制和監控各種工業設備和系統。

Process control: Applicable to the control of processes such as temperature, pressure, flow rate and liquid level.
過程控制：適用于溫度、壓力、流量和液位等過程的控制。

HVAC system: Used for the control and monitoring of HVAC systems.
暖通空調系統：用于 HVAC 系統的控制和監控。

Power plants and substations: Control systems used in power plants and substations.
發電廠和變電站：用于發電廠和變電站的控制系統。

Medical equipment manufacturing: used for the control and monitoring of hospital equipment.
醫療設備制造：用于醫院設備的控制和監控。

Related products
相關產品

This module can be used in conjunction with other ABB products, for example:
該模塊可以與其他 ABB 產品配合使用，例如：

ABB 216EA71 HESG324071R100: Analog input module, used for measuring voltage/current signals.
ABB 216EA71 HESG324071R100：模擬輸入模塊，用于測量電壓/電流信號。

ABB 216EB71 HESG324072R100: Analog output module, used for controlling actuators and valves.
ABB 216EB71 HESG324072R100：模擬輸出模塊，用于控制執行器和閥門。

ABB PM590-ETH HESG324519R101: ABB AC 500 series PLC controller, serving as the central processing unit of this module.
ABB PM590-ETH HESG324519R101：ABB AC 500 系列的 PLC 控制器，作為該模塊的中央處理單元。

Summary
總結

The ABB 216DB61 HESG324063R100/H is a high-performance and highly reliable industrial automation module, suitable for a variety of industrial applications.
ABB 216DB61 HESG324063R100/H 是一款高性能、高可靠性的工業自動化模塊，適用于多種工業應用。

It not only features powerful functions and flexibility, but also has excellent compatibility and scalability, capable of meeting the control requirements in complex industrial environments.
它不僅具備強大的功能和靈活性，還具有良好的兼容性和擴展性，能夠滿足復雜工業環境下的控制需求。

Whether used in industrial automation, process control or other industrial systems, this module can provide stable and efficient solutions.
無論是用于工業自動化、過程控制還是其他工業系統，該模塊都能提供穩定、高效的解決方案。
