描述

ABB AC800PEC 系統 PPD513AOC-100440 3BHE039724R0C3D 800 D513 控制器

The ABB PPD513AOC-1004403BHE039724R0C3D 800 D513 is a high-performance controller produced by ABB and is part of the AC800PEC system. It is mainly used in the fields of industrial automation and power electronics control.
ABB PPD513AOC-100440 3BHE039724R0C3D 800 D513 是 ABB 公司生產的一款高性能控制器，屬于 AC800PEC 系統 的一部分，主要用于工業自動化和電力電子控制領域。

This product is a part of an excitation controller or system controller, widely used in power systems such as power plants, substations, and transmission lines to control and manage the operating status of power equipment.
該產品是一款勵磁控制器或系統控制器的一部分，廣泛應用于發電廠、變電站、輸電線路等電力系統中，用于控制和管理電力設備的運行狀態。



Product Overview
產品概述

This product is a core component in the ABB AC800PEC system and is a standard component of the D513 power cabinet.
該產品是 ABB AC800PEC 系統中的一個核心組件，屬于 D513 功率柜 的標準組件。

Its main function is to convert the input three-phase alternating current (AC) into an AC output with adjustable frequency and voltage, thereby driving medium-voltage motors (rated voltage 2.3-6.9kV, power range 200-5600kW).
其主要功能是將輸入的三相交流電（AC）轉換為可調頻率和電壓的交流輸出，從而驅動中壓電機（額定電壓 2.3-6.9kV，功率范圍 200-5600kW），

It is widely applied to the speed control of large loads such as fans, pumps, compressors and hoists in industries like petroleum and natural gas, metallurgy, mining, power and water treatment.
廣泛應用于石油天然氣、冶金、礦山、電力、水處理等行業的大型風機、泵、壓縮機、卷揚機等負載的調速控制。

Core functions and features
核心功能與特性

Excitation control: This controller can regulate the excitation system of the synchronous generator to maintain voltage stability and optimize reactive power flow.
勵磁控制：該控制器能夠調節同步發電機的勵磁系統，以維持電壓穩定并優化無功功率流動。

High-speed control: This controller features extremely fast analog and digital process I/O, with a typical cycle time of 25 microseconds, making it suitable for power electronics applications with extremely high requirements for speed and precision.
高速控制：該控制器具有極快的模擬和數字過程 I/O，典型循環時間為 25 微秒，適用于對速度和精度要求極高的電力電子應用。

Modular design: Supports modular expansion, facilitating integration into large-scale automation projects.
模塊化設計：支持模塊化擴展，便于集成到大型自動化項目中。

Communication protocol: Supports multiple communication protocols, such as PROFIBUS DP, CANopen, Modbus, etc., to ensure compatibility with different devices and systems.
通信協議：支持多種通信協議，如 PROFIBUS DP、CANopen、Modbus 等，確保與不同設備和系統的兼容性。

Safety and Reliability: Optical link communication is adopted to enhance the security and reliability of the system.
安全與可靠性：采用光鏈路通信，提高系統的安全性和可靠性；

Support redundant design to reduce the risk of single point of failure.
支持冗余設計，減少單點故障的風險。

Environmental adaptability: Suitable for harsh industrial environments, with a working temperature range of -40°C to +70°C.
環境適應性：適用于惡劣工業環境，工作溫度范圍為 -40°C 至 +70°C。



Product parameters
產品參數

Model: PPD513AOC-1004403BHE039724R0C3D
型號：PPD513AOC-100440 3BHE039724R0C3D

Rated voltage: 12 kV
額定電壓：12 kV

Rated current: 630 A
額定電流：630 A

Operation mode: Electric operation
操作方式：電動操作

Protection functions: overcurrent, short circuit, overvoltage, undervoltage, etc
保護功能：過電流、短路、過電壓、欠電壓等

Measurement functions: current, voltage, power, etc
測量功能：電流、電壓、功率等

Input voltage: Supports AC 220V
輸入電壓：支持 AC 220V

Working voltage: 24Vdc/120Vac
工作電壓：24Vdc/120Vac

Operating frequency: 50/60Hz
工作頻率：50/60Hz

Sampling rate: Extremely high, capable of meeting the requirements of high-speed control
采樣率：極高，可滿足高速控制需求

Control algorithms: Supports multiple control algorithms, such as PID, PI, etc
控制算法：支持多種控制算法，如 PID、PI 等

Communication interface: Supports PROFIBUS DP, CANopen, Modbus, etc
通信接口：支持 PROFIBUS DP、CANopen、Modbus 等

Node address range: 0 to 255
節點地址范圍：0 至 255



Product application
產品應用

This product is widely applied in the following fields:
該產品廣泛應用于以下領域：

Power system: Used in power plants, substations, transmission lines, etc., to ensure the stable operation of power equipment.
電力系統：用于發電廠、變電站、輸電線路等，確保電力設備的穩定運行。

Industrial automation: It is used for the automatic control of production lines in industries such as automotive manufacturing, mechanical manufacturing, chemical engineering, oil and gas, food and beverage, etc.
工業自動化：用于汽車制造、機械制造、化工、石油天然氣、食品和飲料等行業的生產線自動化控制。

Wind power generation: A control system for wind turbines to achieve precise control of wind power generation.
風力發電：用于風力渦輪機的控制系統，實現對風力發電的精確控制。

Micro-turbines: Control systems used in micro-turbines to enhance energy utilization efficiency.
微型渦輪機：用于微型渦輪機的控制系統，提高能源利用效率。

LED lighting system: It is used for power control in LED lighting systems, providing high-efficiency conversion and stable current output.
LED 照明系統：用于 LED 照明系統的電源控制，提供高能效轉換和穩定的電流輸出。



Product advantages
產品優勢

High performance: Equipped with advanced processors and hardware technologies, it offers powerful computing capabilities and a fast response speed.
高性能：采用先進的處理器和硬件技術，提供強大的計算能力和快速的響應速度。

High reliability: Through optical link communication and redundant design, the reliability and stability of the system are enhanced.
高可靠性：通過光鏈路通信和冗余設計，提高系統的可靠性和穩定性。

Easy to maintain: The modular design facilitates maintenance and upgrades, reducing maintenance costs.
易于維護：模塊化設計便于維護和升級，降低維護成本。

Environmental protection and energy conservation: The optimized control strategy can reduce the energy consumption of equipment and lower production costs.
環保節能：優化的控制策略可以減少設備的能耗，降低生產成本。



Precautions
注意事項

Professional installation and maintenance: Due to its advanced technology and the particularity of its application fields, it is recommended that installation and maintenance be carried out by professionals.
專業安裝與維護：由于其技術先進性和應用領域的特殊性，建議由專業人員進行安裝和維護。

Customized design: This product may support a certain degree of customized design to meet specific application requirements.
定制設計：該產品可能支持一定程度的定制設計，以滿足特定應用需求。

The ABB PPD513AOC-1004403BHE039724R0C3D 800 D513 is a high-performance excitation controller, suitable for various industrial automation and power electronics control fields. It features high speed, high precision, high reliability and good scalability.
ABB PPD513AOC-100440 3BHE039724R0C3D 800 D513 是一款高性能的勵磁控制器，適用于多種工業自動化和電力電子控制領域，具有高速、高精度、高可靠性和良好的擴展性。
