ABB REC650 | 1MRK008514-CB | 集成化智能電子設備

ABB REC650 1MRK008514-CB is a high-performance intelligent electronic device and is one of the important products in ABB’s (now Hitachi Energy) Relion 650 series.
ABB REC650 1MRK008514-CB 是一款高性能智能電子設備，屬于 ABB（現為 Hitachi Energy）Relion 650 系列中的重要產品之一。

It is a multifunctional Interval Control Unit, widely used in substation automation systems to achieve control, protection, measurement and monitoring functions of various equipment in the power system.
它是一款多功能間隔控制單元（Interval Control Unit），廣泛應用于變電站自動化系統中，用于實現對電力系統中各種設備的控制、保護、測量和監控功能。

I. Product Overview
一、產品概述

The REC650 1MRK008514-CB is an integrated intelligent electronic device (IED), mainly used for Bay Control in substations, capable of achieving comprehensive protection, control, measurement and monitoring functions for transmission lines and cables.
REC650 1MRK008514-CB 是一款集成化智能電子設備（IED），主要用于變電站的間隔控制（Bay Control），能夠?qū)崿F(xiàn)對輸電線路和電纜的全面保護、控制、測量和監控功能。

This equipment is suitable for medium and high voltage transmission systems, especially playing a key role in secondary transmission substations.
該設備適用于中高壓輸電系統，尤其在次級輸電變電站中發揮著關鍵作用。

Ii. Main Functions
二、主要功能

Protection function
保護功能：

Interphase differential protection: Equipped with a highly sensitive interphase differential protection function, it is suitable for the detection of high-impedance faults.
相間差動保護：具備高靈敏度的相間差動保護功能，適用于高阻抗故障的檢測。

Backup distance protection: It provides distance protection function and is suitable for rapid response to line faults.
后備距離保護：提供距離保護功能，適用于線路故障的快速響應。

Overcurrent protection: It can detect and respond to overcurrent conditions to prevent equipment damage.
過流保護：能夠檢測并響應過電流情況，防止設備損壞。

Voltage protection: Monitor abnormal voltage, such as undervoltage or overvoltage, to safeguard system safety.
電壓保護：監測電壓異常，如欠壓或過壓，以保護系統安全。

Control function
控制功能：

Single-phase, two-phase or three-phase tripping: Supports multiple tripping methods to ensure that the system can quickly cut off the circuit in case of a fault.
單相、雙相或三相跳閘：支持多種跳閘方式，確保系統在故障時能夠快速切斷電路。

Automatic reclosing: After the fault is cleared, it can automatically reclose, enhancing the continuous operation capacity of the system.
自動重合閘：在故障清除后，能夠自動重新合閘，提高系統的連續運行能力。

Synchronous control: Supports synchronous control function to ensure the coordination of multiple devices during operation.
同步控制：支持同步控制功能，確保多個設備在操作時的協調性。

Synchronous inspection: It is equipped with a synchronous inspection function to ensure that the equipment is in a synchronous state before closing the switch.
同步檢查：具備同步檢查功能，確保設備在合閘前處于同步狀態。

Monitoring and measurement function
監控與測量功能：

Real-time data monitoring: It can monitor parameters such as current, voltage and frequency in real time, providing data support for system operation.
實時數據監測：能夠?qū)崟r(shí)監測電流、電壓、頻率等參數，為系統運行提供數據支持。

Interval control: By monitoring the distance between devices, the speed, position and acceleration are automatically adjusted to ensure a constant interval between devices and avoid collisions.
間隔控制：通過監測設備之間的距離，自動調整速度、位置和加速度，確保設備間保持恒定間隔，避免碰撞。

Data visualization: Through OPC technology, real-time data is presented in tabular form on web pages, making it convenient for users to view and print reports.
數據可視化：通過 OPC 技術，將實時數據以表格形式展示在網頁上，便于用戶查看和打印報告。

Communication function
通信功能：

Multi-protocol support: Supports multiple communication protocols such as IEC 61850, Modbus, and DNP, facilitating integration with other devices and systems.
多協議支持：支持 IEC 61850、Modbus、DNP 等多種通信協議，便于與其他設備和系統集成。

Network communication: Supports communication interfaces such as CAN bus, RS-232, RS-422, and RS-485 to achieve data exchange with SCADA systems or other control systems.
網絡通信：支持 CAN 總線、RS-232、RS-422、RS-485 等通信接口，實現與 SCADA 系統或其他控制系統的數據交換。

Remote control: Supports remote control function, allowing users to operate and configure the device remotely via the network.
遠程控制：支持遠程控制功能，用戶可以通過網絡對設備進行遠程操作和配置。

Iii. Technical Parameters
三、技術參數

Parameter description
參數 描述

Model REC650 1MRK008514-CB
型號 REC650 1MRK008514-CB

Working voltage: 24V DC
工作電壓 24V DC

Rated current 5A
額定電流 5A

The operating temperature range is -25℃ to +70℃
工作溫度范圍 -25℃ ~ +70℃

The external dimensions are 100mm x 120mm x 50mm
外形尺寸 100mm x 120mm x 50mm

Input voltage AC: 100-240V
輸入電壓 AC 100-240V

Output current 4A (per channel)
輸出電流 4A（每路）

Communication interfaces: 10/100 Mbit/s RJ45 Ethernet interface, RS232/RS485 serial port
通信接口 10/100 Mbit/s RJ45 Ethernet 接口、RS232/RS485 串口

The maximum storage space supports 3TB DDR4 memory
存儲空間 最大支持 3TB DDR4 內存

The warranty period is one year
質保期 1 年

Iv. Application Scenarios
四、應用場景

The REC650 1MRK008514-CB is mainly applied in the following fields:
REC650 1MRK008514-CB 主要應用于以下領域：

Substation automation: It is used to control and protect circuit breakers, disconnectors, grounding switches and other equipment in substations.
變電站自動化：用于控制和保護變電站中的斷路器、隔離開關、接地開關等設備。

Industrial automation: In scenarios such as production lines, logistics systems, and transportation networks, it is used for equipment spacing control and safety monitoring.
工業自動化：在生產線、物流系統、運輸網絡等場景中，用于設備間距控制和安全監控。

Power system: Applicable to interval control and protection in power plants, transmission networks and distribution networks.
電力系統：適用于發電廠、輸電網絡和配電網絡中的間隔控制和保護。

Special environments: Due to its wide temperature range and high reliability, it is also suitable for industrial applications in extreme environments.
特殊環境：由于其寬溫范圍和高可靠性，也適用于極端環境下的工業應用。

V. Advantages and Characteristics
五、優勢與特點

High reliability: Advanced chip technology and modular design are adopted to ensure stable operation even in harsh environments.
高可靠性：采用先進的芯片技術和模塊化設計，確保在惡劣環境下也能穩定運行。

High-precision measurement: It has high-precision measurement capabilities and can accurately monitor parameters such as voltage, current, and frequency.
高精度測量：具備高精度的測量能力，能夠準確監測電壓、電流、頻率等參數。

Flexible configuration: Supports user-defined configuration, allowing parameters and functions to be adjusted according to actual needs.
靈活配置：支持用戶自定義配置，可根據實際需求調整參數和功能。

Easy to maintain: With a modular design, it is convenient for installation, debugging and maintenance, reducing operation and maintenance costs.
易于維護：采用模塊化設計，便于安裝、調試和維護，降低運維成本。

Safe and reliable: Equipped with automatic overcurrent protection, fault alarm and other functions, it ensures the safe operation of the system.
安全可靠：具備自動過流保護、故障報警等功能，確保系統運行安全。

Vi. Summary
六、總結

ABB REC650 1MRK008514-CB is an intelligent electronic device integrating protection, control, measurement and communication, and is widely used in substation automation and industrial automation fields.
ABB REC650 1MRK008514-CB 是一款集保護、控制、測量和通信于一體的智能電子設備，廣泛應用于變電站自動化和工業自動化領域。

Its high performance, high reliability and flexibility make it an indispensable key component in modern power systems and industrial control systems.
其高性能、高可靠性和靈活性使其成為現代電力系統和工業控制系統中不可或缺的關鍵組件。
