描述

MTL5501-SR 通道安全輸入模塊

Installationa)
安裝必須符合相應的歐洲、國家和地方法規，其中可能包括參考IEC實施規范IEC 60079-14。此外，特定行業或最終用戶可能對其設備的安全性有特定要求，這些要求也應得到滿足。對于大多數裝置，指令1999/92/EC [ATEX指令-裝置安全]也適用。

b)本設備為配套電氣設備，通常安裝在非危險[安全]區域。如果滿足相關安裝條件，描述為符合第3類的特定設備可以安裝在第2區位置。當安裝在2區位置時，設備必須提供一個外殼，這是一個適合區域分類的額外保護程度。

c)除非設計已經保護，否則本設備必須有一個合適的外殼保護，以防止:i)機械和熱應力超過認證文件和產品規范中規定的應力;ii)腐蝕性物質，過量的灰塵，水分和其他污染物。有關任何額外或更具體的信息，請參閱下面的安全使用特殊條件。

2區應用的特殊安全使用條件a)在2區使用時
2、設備必須安裝在提供至少IP54防護等級的外殼或環境中，并滿足EN 60079-0:2012和EN 60079-15:2010的相關材料和環境要求。

b)設備不得插入或移除，除非:i)設備安裝的區域已知是無危險的;i)它所連接的電路已經斷電。c)本設備的24V電源必須來自符合歐盟指令要求的穩壓電源。

d)僅適用于5511、5514、5514D、5516C、5517、5526和5532:繼電器觸點可切換至35V、2A和100VA。對于5575:繼電器觸點可以切換到35V, 250mA.e)對于5573最大輸入/輸出參數-見證書。

MTL5501-SR 通道安全輸入模塊

Installationa)
The installation must comply with the appropriate European, national and local regulations,which may include reference to the IEC code of practice IEC 60079-14. In addition, particularindustries or end users may have specific requirements relating to the safety of theirinstallations and these requirements should also be met. For the majority of installations theDirective 1999/92/EC [the ATEX Directive – safety of installations] is also applicable.

b) This apparatus is an associated electrical apparatus and is normally mounted in a non-hazardous [safe] area. Specific apparatus described as Category 3 compliant may beinstalled in a Zone 2 location providing that the relevant installation conditions are met. Whenmounted in a Zone 2 location the apparatus must be provided with an enclosure, whichoffers an additional degree of protection appropriate to the area classification.

c) Unless already protected by design, this equipment must be protected by a suitableenclosure against:i) mechanical and thermal stresses in excess of those noted in the certificationdocumentation and the productspecificationii) aggressive substances, excessive dust, moisture and other contaminants. Read also the Special Conditions for Safe Use (below) for any additional or more specificinformation.

Special Conditions of Safe Use for Zone 2 applicationsa)When used in Zone
2, the equipment must be installed in an enclosure or anenvironment that provides a degree of protection of at least IP54 and meetsthe relevant material and environmental requirements of EN 60079-0:2012and EN 60079-15:2010.

b) The equipment must not be inserted or removed unless either:i) the area in which the equipment is installed is known to be non-hazardousorii) the circuit to which it is connected has been de-energised.c)The 24V supply for this equipment must be derived from a regulated powersupply complying with the requirements of European Community Directives.

d) For 5511, 5514, 5514D, 5516C, 5517, 5526 & 5532 only: Relay contacts mayswitch up to 35V, 2A and 100VA. For 5575: Relay contacts may switch up to 35V, 250mA.e) For 5573 Maximum Input/Output parameters – see certificate.
