產品細節說明：SR489-P5-LO-A20-E GE 發電機管理繼電器

1. 發電機保護：
   • 提供全面的發電機保護功能，包括差動保護、100%定子接地保護、接地方向過流保護、負序過流保護、高整定值過電流保護、低電壓閉鎖過流保護、過/低電壓保護、過/低頻率保護、距離保護和逆功率保護等。
   • 配備大量DSP（數據處理芯片）及1、2個CPU，數據處理由DSP完成，CPU僅進行邏輯判斷，提高運算速度和集成度。
2. 監測與測量：
   • 涵蓋電流有效值、負序電流、電壓、三相功率和12個RTD溫度輸入量的監視。
   • 模擬輸入支持4-20mA、0-20mA或0-1mA，并可設置最小、最大值及單位，具有阻塞、低于或超過閾值、跳閘或報警、延遲等功能。
3. 顯示與操作：
   • 具有一個40個字符的顯示屏，允許用戶查看值消息、診斷和設置點。
   • 前面板包括多個狀態LED、輸入按鈕、數字鍵盤、輸入端口和用于讀取設備位置信息的LCD屏幕，便于用戶查看和操作繼電器的狀態和功能。
4. 通信與接口：
   • 后面板包括十二個RTD輸入、六個輸出繼電器、兩個RS485通信端口和四個VT輸入。
   • 通信端口支持ModbusRTU或DNP 3.0協議（或兩者），最高可達19200 bps。
   • 還包括四個隔離的4-20 mA模擬輸入和輸出以及七個可分配的數字輸入。
5. 電氣參數：
   • 繼電器可以在25、50或60赫茲下運行，頻率參數范圍為0.00到90.00 Hz。
   • 零線電壓（第3個）參數范圍為0至25000 V，功率因數參數范圍為0.01至1.00超前/滯后，無功功率（Mvar）參數范圍是額定電壓的-2.00至2.00倍。
6. 設計與安裝：
   • 結構緊湊、體積小巧，易于安裝和維護。
   • 裝運重量約為10千克（近似值），尺寸為21.6厘米（長）×22.4厘米（寬）×25.2厘米（高）。

產品詳情參數 ：SR489-P5-LO-A20-E GE 發電機管理繼電器

• 擴展接口：雖然直接關于SR489-P5-LO-A20-E的擴展接口信息有限，但類似產品可能包含如PCI-104插槽等用于多功能應用擴展的接口。
• 可靠性與壽命：具有高可靠性、長壽命的特點，能夠保持發電機的穩定運行，提高發電效率。

SR489-P5-LO-A20-E GE? 應用領域：

SR489-P5-LO-A20-E是一款功能全面、技術成熟的發電機管理繼電器，適用于各種發電機管理和保護應用。其強大的保護功能、豐富的監測與測量功能、便捷的顯示與操作界面以及靈活的通信與接口設計，使得該產品在工業自動化領域具有廣泛的應用前景。

Product details: SR489-P5-LO-A20-E GE Generator Management Relay
Generator protection:
Provide comprehensive generator protection functions, including differential protection, 100% stator grounding protection, grounding direction overcurrent protection, negative sequence overcurrent protection, high setting overcurrent protection, low voltage lockout overcurrent protection, over/low voltage protection, over/low frequency protection, distance protection, and reverse power protection.
Equipped with a large number of DSP (data processing chips) and 1 or 2 CPUs, the data processing is completed by the DSP, and the CPU only performs logical judgments to improve computational speed and integration.
Monitoring and measurement:
Monitoring covering effective current value, negative sequence current, voltage, three-phase power, and 12 RTD temperature inputs.
Analog input supports 4-20mA, 0-20mA, or 0-1mA, and can be set with minimum, maximum values, and units. It has functions such as blocking, below or exceeding threshold, tripping or alarm, delay, etc.
Display and operation:
A 40 character display screen that allows users to view value messages, diagnostics, and set points.
The front panel includes multiple status LEDs, input buttons, numeric keyboards, input ports, and LCD screens for reading device location information, making it easy for users to view and operate the status and functions of relays.
Communication and Interface:
The rear panel includes twelve RTD inputs, six output relays, two RS485 communication ports, and four VT inputs.
The communication port supports ModbusRTU or DNP 3.0 protocol (or both), up to 19200 bps.
It also includes four isolated 4-20 mA analog inputs and outputs, as well as seven assignable digital inputs.
Electrical parameters:
The relay can operate at 25, 50, or 60 Hz, with frequency parameters ranging from 0.00 to 90.00 Hz.
The parameter range for zero line voltage (3rd) is 0 to 25000 V, the power factor parameter range is 0.01 to 1.00 lead/lag, and the reactive power (Mvar) parameter range is -2.00 to 2.00 times the rated voltage.
Design and installation:
Compact structure, compact size, easy to install and maintain.
The shipping weight is approximately 10 kilograms (approximately), with dimensions of 21.6 centimeters (length) x 22.4 centimeters (width) x 25.2 centimeters (height).
Product details parameters: SR489-P5-LO-A20-E GE generator management relay
Expansion Interface: Although there is limited information about the expansion interface directly related to SR489-P5-LO-A20-E, similar products may include interfaces such as PCI-104 slots for multifunctional application expansion.
Reliability and lifespan: It has the characteristics of high reliability and long lifespan, which can maintain the stable operation of the generator and improve power generation efficiency.
SR489-P5-LO-A20-E GE application areas:

SR489-P5-LO-A20-E is a comprehensive and technologically mature generator management relay suitable for various generator management and protection applications. Its powerful protection functions, rich monitoring and measurement functions, convenient display and operation interface, and flexible communication and interface design make this product have broad application prospects in the field of industrial automation.
