TM3AI8 Schneider 8 路模擬量輸入模塊 成都陽光熹禾

TM3AI8 Schneider 8 路模擬量輸入模塊 成都陽光熹禾

  • 重量：TM3AI8 模塊的重量為 110 克（3.88 盎司），TM3AI8G 模塊的重量為 100 克（3.52 盎司）。
  • 額定電源電壓：24 Vdc，電源范圍 20.4…28.8 Vdc，連接器插入/拔出耐久性至少 100 次。
  • 5 Vdc 內部總線上的最大電流：無負載時 35 mA，滿負載時 35 mA，24 Vdc 內部總線上的最大電流為 0 mA，外部 24 Vdc 時的最大電流無負載時 30 mA，滿負載時 40 mA。
分類：

描述

產品細節說明：TM3AI8 Schneider 8 路模擬量輸入模塊

  • 輸入通道：模塊提供 8 個獨立的 12 位模擬輸入通道，可以接收電壓或電流信號。
  • 信號類型：支持的信號類型包括 0 至 10 Vdc 和 -10 至 +10 Vdc 的電壓信號，以及 0 至 20 mA、4 至 20 mA 和 0 至 20 mA 擴展型、4 至 20 mA 擴展型的電流信號。
  • 電源規格：模塊的額定電源為 24 Vdc，電源電壓范圍是 20.4 Vdc 至 28.8 Vdc。
  • 連接類型：TM3AI8 提供可插拔螺釘端子塊，而其變體 TM3AI8G 提供可插拔卡簧端子塊，以適應不同的安裝需求。
  • 電纜類型和長度：推薦使用屏蔽雙絞線，最大長度可達 30 米（98 英尺）。
  • 狀態 LED 指示：模塊上有 PWR 綠色 LED 指示燈，亮起表示已接通 TM3 總線電源，熄滅表示已斷開 TM3 總線電源?。

TM3AI8

產品詳情參數 ：TM3AI8 Schneider 8 路模擬量輸入模塊

  • 重量：TM3AI8 模塊的重量為 110 克（3.88 盎司），TM3AI8G 模塊的重量為 100 克（3.52 盎司）。
  • 額定電源電壓：24 Vdc，電源范圍 20.4…28.8 Vdc，連接器插入/拔出耐久性至少 100 次。
  • 5 Vdc 內部總線上的最大電流：無負載時 35 mA，滿負載時 35 mA，24 Vdc 內部總線上的最大電流為 0 mA，外部 24 Vdc 時的最大電流無負載時 30 mA，滿負載時 40 mA。

TM3AI8 Schneider? 應用領域：

TM3AI8 模塊適用于多種工業自動化應用，可以與 Modicon M221、M241、M251 和 M262 邏輯控制器配合使用，是 MachineStruxure 輸入/輸出系統的一部分。模塊的高精度和高分辨率特性使其非常適合用于精確測量和控制。

Product details: TM3AI8 Schneider 8-channel analog input module
Input channels: The module provides 8 independent 12 bit analog input channels that can receive voltage or current signals.
Signal types: The supported signal types include voltage signals from 0 to 10 Vdc and -10 to+10 Vdc, as well as current signals from 0 to 20 mA, 4 to 20 mA, 0 to 20 mA extension, and 4 to 20 mA extension.
Power specifications: The rated power supply of the module is 24 Vdc, and the power supply voltage range is 20.4 Vdc to 28.8 Vdc.
Connection type: TM3AI8 provides pluggable screw terminal blocks, while its variant TM3AI8G provides pluggable card spring terminal blocks to meet different installation requirements.
Cable type and length: It is recommended to use shielded twisted pair cables, with a maximum length of up to 30 meters (98 feet).
Status LED indicator: There is a PWR green LED indicator on the module, which lights up to indicate that the TM3 bus power has been connected, and goes out to indicate that the TM3 bus power has been disconnected.
Product details and parameters: TM3AI8 Schneider 8-channel analog input module
Weight: The weight of the TM3AI8 module is 110 grams (3.88 ounces), and the weight of the TM3AI8G module is 100 grams (3.52 ounces).
Rated power supply voltage: 24 Vdc, power supply range 20.4… 28.8 Vdc, connector insertion/extraction durability of at least 100 times.
The maximum current on the 5 Vdc internal bus is 35 mA at no load and 35 mA at full load. The maximum current on the 24 Vdc internal bus is 0 mA, and the maximum current on the external 24 Vdc bus is 30 mA at no load and 40 mA at full load.
TM3AI8 Schneider Application Fields:

The TM3AI8 module is suitable for various industrial automation applications and can be used in conjunction with Modicon M221, M241, M251, and M262 logic controllers. It is part of the input/output system of the MechaniStruxure. The high precision and resolution characteristics of the module make it very suitable for precise measurement and control.
